PARTS LIST
25
Part No. Model No. Description
Qty
1 31103463-1 1
1-1 33304250-1 Upper bail 1
1-2 34115250 Sponge 1
1-3 33305250-1 Lower bail 1
1-4 3220439 Nut M5 7
1-5 33323250 1
1-6 32208234 Bolt M5*30 1
1-7 33303250-2 Upper handle 1
2 32204234 Bolt M6*35 1
3 3220537 Nut M6 1
4 31903250 1
5 32204283 Bolt 2
6 34108283 Knob 2
7 3411135 Cord guide 1
8 33302463-1 Lower handle 1
9 33901250
Pulley
Drive cable
Cable assy.
Bail stop
1
10 34101234 Rear cover 1
11 33313234 Spring for rear cover (R) 1
12 33201234 Axle for rear cover 1
13 3290506 Clip 2
14 33310234 Spring for rear cover (L) 1
15 33904234 Height adjustment plate (R) 1
16 32207234 Bolt M10*20 4
17 3220737 Nut M10 4
18 32205234 Screw ST6.3*16-F 4
19 3220150 Screw M6*15 2
20 32906131 Spring washer 2
21 3231235 Washer 2
22 34108234
Grommet
1
23 31301463-1 Deck 1
24 32202234 Bolt 1
25 34103463 Belt cover 1
26 34113227-1 Height adjustment knob (upper) 1
27 34114227-1 Height adjustment knob (lower) 1
28 33304234 Height adjustment bar 1
29 32209234 Screw M5*12 4
30 33303234 Spring board 1
31 3220550 Screw M5*12 4
32 34104234
Wheel dust cover
2
33 31101463 Wheel assy. 2
34 34203229-4 Wheel 2
To Next Page
