Yardworks 060-3864-2 User Manual

11
Assembling handles
Installing the lower handle
1. Insert the lower handle (2) into the housing hole. Place rubber pad (1) between the
housing and lower handle.
2. Using the supplied screws (3), fasten the lower handle to the housing using a star-
shaped screwdriver, not supplied.
Installing the upper handle
1. Position the upper handle so the holes line up with the lower handle holes.
2. Insert the supplied hex bolt (1) through the hole from the outside of the handle bar.
3. Thread the knob (2) onto the hex bolt to tighten securely into place.
Fig. 3
2
2
3
1
1
1
2
2
1
