22
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 34104142-4 blower tube 1
2 36101141B 12A motor assy. Blower/Mulcher 1
3 34105148-4 switch cover 1
4 31102148-1 housing assy. 1
5 3220313 screw 19
6 34901148 dustproof sponge 1
7 3410801 cord clip 1
8 3420102-1 strain relief 1
9 3650339 cord connector 2
10 36409142 power cord 1
11 3410679-11 lock button for blower tube 1
12 34201148 shockproof pad 4
13 3320128 bushing 1
14 34112142 impeller 1
15 3340427 washer 1
16 3410127-1 impeller nut 1
17 34105142-4 mulcher cover 1
18 33401145 torsion spring 1
19 34201142 rubber washer 1
20 31104148-1 lock button assy 1
21 34106142-4 upper mulcher tube 1
22 34107142-2 lower mulcher tube 1
23 37901142-2 collection bag assy 1
24 34115142-1 concentrator nozzle 1
