14
W A R N I N G
Do not allow familiarity with this product to make you careless. Remember that a careless
W A R N I N G
Always wear safety goggles or safety glasses with side shields when operating power tools. Failure
to do so could result in objects being thrown into your eyes, resulting in possible serious injury.
W A R N I N G
Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
ASSEMBLING THE HANDLE (See Figure 3-4)
• Remove any packing material which may be between the upper and lower handles for
shipping purposes.
• Pull up and back on the upper handle to raise the handle into the operating position. Make
certain the lower handle is
seated securely into the handle mounting bracket (see Fig. 3).
• Align the holes (3) between the upper handle (1) and lower (2) handles. Insert
the cam locks (4)
and tighten them with the wing nuts (5) provided.
• Secure the lower handle to the bracket with the knob (6) in each side (see Fig. 4).
ASSEMBLY INSTRUCTIONS
Fig. 4
Fig. 3
435
1
2
6
To Next Page
