model number 060-1809-8 | contact us: 1.866.523.5218 model number 060-1809-8 | contact us: 1.866.523.5218
11
MOUNTING
Proper use
This tiller is only intended for scarifying/aerating (loosening and aerating of the lawn). It is only
suitable for domestic use in home and hobby gardens.
Improper use
The tiller must not be used in permanent operation and not in industrial environments.
ASSEMBLY
This product must be assembled correctly before use.
!
WARNING! Do not connect to power supply until assembly is complete. Failure to comply
could result in accidental starting and possible serious personal injury.
1.FITTING THE CORD RETAINER (See Fig. A)
Simply attach the cord retainer (16) by inserting it through the upper handle (4).
2.FITTING THE HANDLE
Assembling the middle handle with lower handle (SEE FIG. B1)
1) Attach the middle handle to the lower handle, align the hole on the middle handle with the
hole on lower handle.
2) Insert the locking bolt (6) for middle handle through the aligned holes on middle and lower
handles.
3) Insert the locking knob (13) for middle handle through the bolt and turn it clockwise to
tighten.
4) Repeat the above steps to assemble the other side of the middle handle.
Assembling the middle handle with upper handle (SEE FIG. B2)
5) Attach the upper handle to the middle handle, align the hole on the middle handle with the
hole on upper handle.
6) Insert the locking bolt (4) for upper handle through the aligned holes on middle and upper
handles.
7) Insert the locking knob (15) for middle handle through the bolt and turn it clockwise to
tighten.
8) Repeat the above steps to assemble the other side of the upper handle.
3.FITTING AND ADJUSTING THE WHEELS
The wheels are used to control the depth of operation and for transport.
