Yealink SIP-T33P Recovery Guide

Recovery Mode on Yealink IP phones
7
2. Press 1 to run the backup system.
Note
Using Recovery Mode on Yealink IP Phones
(HTTP Server)
This section introduces how to perform recovery mode using the HTTP server on Yealink IP phones step
by step.
For SIP Phone Series
This section is only applicable to SIP phone series including SIP-T27G, SIP-T30, SIP-T30P, SIP-T31,
SIP-T31P, SIP-T31G, SIP-T33P, SIP-T33G, SIP-T41S, SIP-T42S, SIP-T46S, SIP-T48S, SIP-T58A,
CP960, and CP920.
This feature can only be supported on new factory phones running firmware version 86 or later.
Procedures
1. Long press (Speakerphone key) and reconnect the power adapter to trigger the recovery
mode. Do not release until the recovery mode wizard appears on the phone LCD screen.
2. Press 1 to use the HTTP server.
For CP965/CP925 IP phones, you need to power on the device and long tap the Home touch
key when the Mute LED indicator glows red to trigger the recovery mode.

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
