Yealink SIP-T38G Installation Guide

Startup
CD-ROM
1. Attach the stand, as shown below:
2. Connect the handset and optional headset, as shown below:
3. Connect the network and power, as shown below:
Internet
a. AC Power Option
b. PoE (Power over Ethernet) Option
The following items are included in your package. If you find anything missing, contact your
system administrator.
Packing List
Assembling the Phone
Note: If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the Ethernet
cable and hub/switch are PoE compliant.
Stand
Power Adapter
Handset Cord
Handset
IP Phone
Ethernet Cable
Quick Installation
Guide & Quick
Reference Guide
Power Adapter
(DC 5V)
PC Connection
(Optional)
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch
Stand attached
Note: The headset should be purchased separately.
SIP-T38G Quick Installation Guide www.yealink.com
You have two options for network and power connections. Your system administrator will advise
you on which one to use.
After the IP phone has been connected to the
network and supplied with power, it automatically
begins a process of initializing itself on the network.
After that, you can begin to configure the phone via
Web user interface or phone user interfafce.

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
