Yealink SIP-T53W Auto Provisioning Guide

Triggering the IP Phone to Perform Auto Provisioning
47
The IP phone downloads the specified configuration files in sequence in boot files from the
provisioning server to complete phone configurations. For more information on boot files
and configuration files, refer to Managing Boot Files and Managing Configuration Files.
The following parameters are used to configure the auto provisioning via activation code
method (X ranges from 1 to 50):
#(Optional.) Configure the code name for triggering auto provisioning.
static.autoprovision.X.name
#Configure the activation code.
static.autoprovision.X.code
#Configure the URL of the provisioning server.
static.autoprovision.X.url
#Configure the username and password for downloading boot files and configuration files. If
configured, the LCD screen will not prompt for user name and password.
static.autoprovision.X.user
static.autoprovision.X.password
The entered user name and password will be saved to the IP phone for next auto provisioning.
The LCD screen will not prompt for user name and password if the provisioning server does not
require authentication, or the user name and password are already saved on the IP phone.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
