Page 2 | Copyright © Telair Pty Ltd (ABN 92 119 713 745) | www.telair.com.au | 1800 telair (835 247) Page 3 | Copyright © Telair Pty Ltd (ABN 92 119 713 745) | www.telair.com.au | 1800 telair (835 247)
Layout & Features:
How to:
PLACE A CALL
Using a handset:
1. Pick up handset.
2. Enter number and press the Send soft key.
Using a headset:
1. With the headset connected, press to activate headset mode.
2. Enter number and press the Send soft key.
Using speakerphone:
1. With the handset on-hook, press .
2. Enter number and press the Send soft key.
ANSWER/END A CALL
Using a handset:
Pick up handset / Return handset or press End Call soft key.
Using a headset:
Press .
Using speakerphone:
Press .
TRANSFER A CALL
Blind Transfer - The call is transferred directly without the need to announce the caller:
1. Press the Transfer soft key during the active call to place the call on hold.
2. Enter the receiving number you want the call transferred to.
3. Press the B Transfer soft key.
Attended Transfer - Allows you to announce the caller prior to releasing the call:
1. Press the Transfer soft key during the active call to place the call on hold.
2. Enter the number you want to transfer to and press .
3. When the second party answers, announce the call and then press Transfer soft key.
ACCESS VOICEMAIL
1. Press or press the Connect soft key.
2. When prompted, enter PIN-Code and press .
For new messages, press .
For saved messages, press .
For advanced voicemail settings, press .
MANAGE CALL HISTORY
1. Press the History soft key to view the Placed, Received or Missed call log.
2. Press or to scroll through the list.
Press the Send soft key to place a call to the highlighted entry.
Press the Delete soft key to delete the highlighted entry from the list.
Press the Option soft key and select Add to Contacts to add the entry to the local directory or
select Add to Blacklist to add the entry to the blacklist.
ADD A NEW CONTACT
1. Press the Directory soft key and then select All Contacts.
2. Press the Add soft key to add a contact.
3. Select the Directory the contact will be added to.
4. Enter the contact’s Name and Number.
5. Press the Save soft key.
You can alternate between headset, speakerphone and handset by pressing the
corresponding key.
Soft Keys
LCD Screen
Headset Key
Mute Key
Redial Key
Message Key
Speakerphone
Key
Dial Pad
Navigation Keys
Volume Key
Speaker

Other manuals for Yealink SIP-T53W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T53W and is the answer not in the manual?

Yealink SIP-T53W Specifications

General IconGeneral
MountingDesk/Wall
Handset typeWired handset
Product typeIP mobile phone
Product colorGray
Keypad illuminationYes
Wi-Fi standards802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Security algorithmsAES, HTTPS, SIPS
Networking standardsIEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface typeGigabit Ethernet
Supported network protocolsFTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Lines quantity8 lines
Phonebook capacity1000 entries
Number of VoIP accounts12
AC adapter input voltage100 - 240 V
AC adapter output current1.2 A
AC adapter output voltage5 V
Power consumption (typical)2.3 W
Volume controlButtons
Number of programmable keys8
Storage temperature (T-T)-30 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Display diagonal3.7 \
Display resolution360 x 160 pixels
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Number of DECT wireless handsets4
Voice codecsG.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC
Weight and Dimensions IconWeight and Dimensions
Depth210.6 mm
Width212 mm
Height174.5 mm
