Yealink T31 Quick Installation Guide

T31P/T31G/T31/T30P/T30
:
Screw position
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Screw position
x 2
100mm
100mm
85mm
85mm
124mm
100mm
T33G/T33P
:
Yealink provides the wall mount drilling templates, which locate and mark
the position for mounting the screws (not provided) on the wall, as shown
below:
Yealink liefert die Bohrschablonen für die Wandmontage, welche die Position für die
Befestigung der Schrauben (nicht mitgeliefert) an der Wand orten und markieren, wie
unten dargestellt:
Yealink proporciona las plantillas de perforación para montaje en pared, que ubican y
marcan la posición para montar los tornillos (no incluidos) en mural, como se muestra
a continuación:
Yealink fournit les gabarits de perçage pour le montage mural, qui permettent de
localiser et de marquer la position des vis (non fournies) sur le mur, comme indiqué
ci-dessous :
Mounting the Screws
1
Befestigung der Schrauben | Tornillos de montaje | Fixer les vis

Yealink T31 Specifications

General

Wall Mountable	Yes
Opus Codec	Yes
Display	2.3-inch 132x64 pixel graphical LCD
Network	10/100 Mbps Ethernet
PoE	Yes
Audio Features	HD Voice, Full-duplex hands-free speakerphone with AEC
Headset Support	RJ9 headset port
Local Phonebook	1000 entries
Supported Protocols	SIP v1 (RFC2543), v2 (RFC3261)
Power Supply	DC 5V/600mA
Operating Temperature	0°C to 40°C
Humidity	10% to 95%, non-condensing
Compliance	FCC, CE
SIP Accounts	2 SIP accounts
