Table of Contents Page
Important Notices to Purchaser
Warning
Features of Your New Pump...................................................................................3
The Purpose of the SuperEvac
™
PLUS II Design......................................................4
Important Steps of Initial Start-up...........................................................................5
Vacuum Tips for Best Performance.........................................................................5-6
Dual Voltage Motor Power Conversion....................................................................6
Basic Troubleshooting............................................................................................7
• Four Most Common Problems
• Oil Leakage
• The Steps to Solving 95% of All Problems
Diagnostic Chart....................................................................................................8, 9
Replacement Parts................................................................................................10, 11
Warranty and Service............................................................................................12
Check for damage immediately.
Prior to shipment, all YELLOW JACKET
®
SuperEvac
™
PLUS II vacuum pumps are
completely tested and inspected to assure
compliance with Ritchie Engineering
factory specifications.
If the pump carton is damaged, check
contents immediately. Note damage on
shipper’s Bill of Lading and have shipper
sign your statement. Notify the carrier
immediately of the damage to arrange
inspection of the pump and packaging.
The CARRIER ALONE is responsible for
handling and settling your claim. Ritchie
Engineering will cooperate in assessing
damage if the pump is returned to the
factory prepaid.
CARTON CONTENTS INCLUDE:
• SuperEvac
™
PLUS II Pump
• Bottle of YELLOW JACKET
®
SuperEvac
™
Pump Oil
• Shoulder Strap
• Locking, Removable Power Cord
• Owner’s Manual
• This unit generates a deep vacuum that can be harmful to human tissue. Do not expose
any part of the human body to the vacuum.
• Do not operate this unit with the exhaust blocked or restricted. Remove red shipping
cap prior to use.
• Keep unit a minimum of 4” (10 cm) from objects to provide adequate cooling of motor.
• Continuous sound pressure level of this unit can exceed 70dB (A).
• Wear goggles and protective clothing when using this product.
• Designed for use with A2L systems.
• This unit is only rated as non-sparking. Not intended for use in Zone 0 or Zone 1
hazard areas.
Warranty is void if the set vacuum pump voltage does not match the power supply.
