9.3.Information interface
9.4.Manual control interface
on
Tilt reversal
off
on
Pan and Tilt exchange
off
on Exchange XY channels(including fine turning)
Pan and Tilt encoder
On
Use encoder (light coupling) to judge the wrong
step and correct it automatically.
off Not use encoder(light coupling) to correct position
Without DMX Signal
retain Keep the original state to continue running
clear Motor return, and stop running
Screen saver
on 30 seconds later, it will close the backlight
off Backlight on forever
Boot light bubble
off
reset directly after Power on ,if not,need to use
the menu or control table to turn it on manually.
on
Light on automatic after power on,and can not reset
until the light bulb on successfully
Restore default settings
Click “OK”button to see the confirmation dialog
box,then click “OK”button again to restore default
settings.
options illustration
Software version The current software version
Total used time Accumulative total used time(accurate to minutes)
This time of use Since the boot the use of time(accurate to minutes)
DMX channel value Enter into the sub interface,the numerical and percentage displayed
channel value for reference.
System error record If the red light”ERR”shine,it indicates the operational error of lamps
and lanterns,the details please check in the sub interface.
After the check,you can click “OK”button to empty the error record.
options Illustration
reset Click”OK”button to see confirmation dialog
box,click”OK”again, then enter reset interface,then after all
motor reset.
Color wheel 0-255 Press “OK”button to enter edit state.at the same time,choose
