YOKOGAWA 734 01 User Manual

41
● Calibration of Capacitor Range
Before start calibration of the Capacitor range,
turn the function switch back to the OFF position.
1) Turn the function switch from the OFF position to the (Capacitor)
position while pressing the SELECT and RANGE keys at the same time.
The display shows the “ CAL ” symbol then the “ PASS ” symbol.
2) Press the SELECT key. (The display shows the “ - ” symbol.)
3) Press the HOLD key twice. (The display shows the “ - - - ” symbol.)
4) Press the RANGE key. (The display shows the “ nF ” symbol.)
5) Connect the instrument to the calibrator with the testing leads.
6) Set the calibrator to Input 1 value as an input to the instrument.
7) Press the HOLD key to confirm.
8) Set the calibrator to Input 2 value as an input to the instrument.
9) Press the HOLD key to confirm.
10) Carry out calibration of other ranges by repeating steps 6) to 9).
11) To quit calibration, turn the function switch back to the OFF position.
5nF
50nF
500nF
5µF
50µF
500µF
5mF
50mF
0.500
5.00
50.0
0.500
5.00
50.0
0.500
5.00
5.000
50.00
500.0
5.000
50.00
500.0
5.000
40.00
nF
nF
nF
µF
µF
µF
mF
mF
Input 1 Input 2 UnitRange
