5. System Functions After Upgrade
5-13
TI 33K01B10-50E
Table Action Signals Description (2/2)
Type
CENTUM V CENTUM-XL Upgraded FCS
Output
signal
Action
spec.
Output signal
Action
spec.
Output signal Action spec.
CENTUM
instrument
preset MV
Tag name MV, MC Tag name.MV
0
100
PMV
Element name.PSW
1
2
3
CENTUM
instrument
pulse-width
output reset
Tag name PW Tag name.PW Element name.RSW 1
Switch
instrument
output status
Tag name.MV 0, 1, 2 Element name.CSV
0, 1, 2
P0
P1
P2
Switch
instrument loop
status
Tag name.S
MAN
AUT
CAS
DDC
Element name.
MODE
MAN
AUT
CAS
ROUT
BUM Element name.TSW 1
Switch
instrument
alarm status
Tag name.S
CAL Element name.PV =CAL
AOF
Element name.
AOFS
AOF
Batch status
indicator
Tag name.PV 0 to 15 Element name.PV 1 to 99
Tag name.SV 0, 1, 2
Element name.
PV01 to PV10
0, 1
Arithmetical
expression
NCLnnn %CLnnn Element name.ACT ON
Resource
scheduler
%RMnnn.RQ
0 Element name.ACT ON/OFF
1 to 32
Element name.
RQ01 to RQ32
0, 1
%RMnnn.N 0 to 32 Element name.PMH 0 to 32
Message output NSMnnn m
m: Device
number
%PRnnn
%OGnnn
%VMnnn
%RQnnn
%PDnnn
%M3nnn
%M6nnn
mmm
(0 to 65534)
Element name.PV
NON
mmm
(-32768 to 32767)
Thefollowingshowsoutputsignalsandactionspecicationsthatwerenewlyaddedtoa
upgraded FCS.
Table Signal Column
Type
Action signal column
Action
rule
Action description
Output signal Action spec.
Contact output Element name.PV P
Y
Output1secondofpulsetothespeciedbit.
N Invalid
Alarm detection status
of function block
Element name.XAF IOP
Y Do not detect IOP or IOP- alarm.
N Detect IOP and IOP- alarms.
Sequence table Element name.XS ON
Y Execute/resume sequence table.
N Suspend sequence table.
Software counter Element name.XACT ON
Y Activate software counter. (Increment by 1)
N Stop software counter.
CAL of function block
Element name.PV
Element name.CPV
=XCAL
Y Switch status between CAL and NOT CAL.
N Invalid
Mar. 27, 2015-00
