Appendix 1. Signal Conditioner Models
App.1-2
TI 33K01B10-50E
(2) CENTUM-XL System
Type Model Name
Signal conditioner nest
ENC I/O signal conditioner nest
ENM Control I/O signal conditioner nest
MHC I/O signal conditioner nest
MHM Control I/O signal conditioner nest
Signal conditioner power supply
PS40 Power unit (24 V DC)
PS41 Power unit (220/230/240 V AC)
Input signal conditioner card
ET5 Thermocouple input card
ER5 RTD input card
ES1 Potentiometer input card
EM1 mV input card
EH1 Input isolator card (1-5 V input)
EH5 Input isolator card (1-5 V input, w/square root extraction)
EA1 2-wire transmitter input card
EA2 2-wire transmitter input card (w/communication function)
EA5 2-wire transmitter input card (1-5 V, w/square root extraction)
EP1 Pulse-train input card
EP3 Frequency input card
EA9 I/O Non-isolated distributor
Output signal conditioner card
EC0 Control output isolator card
EA0 Output isolator card (4-20 mA output)
EH0 Output isolator card (1-5 V output)
Common card
ESC Signal conditioner communication card
EXT Extension card
EX1 I/O through card
Mar. 27, 2015-00
