YOKOGAWA Centum-XL User Manual

Appendix 3. Tuning Parameter Differences
App.3-3
TI 33K01B10-50E
CENTUM V
Instrument type
CENTUM VP
Function block
CENTUM V
Data type
CENTUM VP
Data item
Conversion
equation
7DS DSET-PVI PV CPV
PH SVH
PL SVL
7PG, 7PG-BR/SP PG-L13 K4 ZONE
K7 CALC (*1)
D1 to DE Y01 to Y14
X1 to XE X01 to X14
7CM-EX LAG No difference except "Common"
7CM-DR LD No difference except "Common"
7CM-UF RAMP I STEP
7CM-LL LDLAG No difference except "Common"
7CM-LA/L1/L2 DLAY D SMPL
7CM-LC/L3/L4 DLAY-C D SMPL
7CM-AV/A1/A2 AVE-M I NUM
D SMPL
K7 PREV
7CM-1A AVE-C SV SW
K3 PREV
7CM-NL/XY FUNC-VAR No difference except "Common"
7CM-CL CALCU K4 (None)
RD RV
7BS BSETU-2 SV SW
PL (None)
VL LPV
I TU
D TD
DL (None)
K8 x K9 BSET (*17)
PL x K9 ILST (*18)
DL x K9 PLST (*19)
7BD BDSET-1L SV SW
K1 to K9,
KA to KE
DT01 to DT09,
DT10 to DT14
(*13)
7BD-B2 BDSET-2L NX NXBS
K1 to K9,
KA to KE
DT01 to DT09,
DT10 to DT14
(*13)
D1 to D9,
DA to DE
NX01 to NX09,
NX10 to NX14
7BC BDA SV SW
K1 to K9,
KA to KE
DT01 to DT09,
DT10 to DT14
(*13)
Mar. 27, 2015-00
Table Tuning Parameters Difference between CENTUM V and CENTUM VP(3/5)
