YOKOGAWA Daqstation DX1000N Series User Manual

64 IM 04L41B01-02E
Math channel > Partial
Setup Item Selectable Range or Selections Default Value Setting
First-CH, Last-CH 101/102/.../124 (Depends on the model.) 101
On/Off On/Off Off
Expand 1 to 99% 50
Boundary Span Lower+1digit to Span Upper–1digit 0.00
Math channel > Alarm mark
Setup Item Selectable Range or Selections Default Value Setting
First-CH, Last-CH 101/102/.../124 (Depends on the model.) 101
Mark kind Alarm/Fixed Alarm
Indicate on Scale On/Off Off
Alarm mark color > Alarm 1 Red/Green/.../S.green (24 colors) Red
Alarm mark color > Alarm 2 Same as Alarm 1 Orange
Alarm mark color > Alarm 3 Same as Alarm 1 Orange
Alarm mark color > Alarm 4 Same as Alarm 1 Red
Math channel > Color scale band
Setup Item Selectable Range or Selections Default Value Setting
First-CH, Last-CH 101/102/.../124 (Depends on the model.) 101
Band area Off/In/Out Off
Color Red/Green/.../S.green (24 colors) Lime
Display position > Lower Measuring range 0.00
Display position > Upper Measuring range 1.00
Math channel > Math start action
Setup Item Selectable Range or Selections Default Value Setting
Math start Off/Start/Reset+Start Start
Setup Items and Default Values
