YOKOGAWA Daqstation DX2048 - Displaying Comments (Release Number 3 or Later)

5-42
IM 04L42B01-01E
5.19 DisplayingComments(Releasenumber3or
later)
Register text strings to comment text fields and combine comment text fields to create
comment text blocks.
• Youcandisplay the text from a comment text block when a certain event occurs (an
alarm for example).
• Youcanusecommenttextblocktextforannunciatorwindowlabels(seesection3.12
for details).
SetupScreen
• EnteringComments
Press MENU (to switch to setting mode), and select the Menu tab > Message,
CommentText > Commenttxtfields.
Press MENU (to switch to setting mode), and select the Menu tab > Message,
CommentText > Commenttxtblock.
• DisplayingComments
Press MENU (to switch to setting mode), and select the Menu tab > Timer,Event
action > Eventaction
See section 7.1.
