Appendix 2. VLAN-based routing
App.2-5
TI 30A10A30-01E
ConfirmVLAN-basedroutingconfiguration
For more information of the example of the VLAN-based routing configuration, “show running-
config” display is as shown below. Confirm if the modified configuration are valid by comparing
the following examples.
VLAN-basedroutingconfiguration(1/4)
F0A0208.ai
(Hirschmann MACH) #show running-config
!Current Configuration:
!
!Parameter string escape handling \, 1
!Characters to be preceded with escape char (\): \, !, ", ', ?
!System Description "Hirschmann MACH"
!System Version L3P-06.0.01 Build: 2010-09-25 12:58
vlan database
vlan 11
vlan 12
vlan 13
vlan 14
vlan routing 11
vlan routing 12
vlan routing 13
vlan routing 14
exit
network protocol none
network protocol hidiscovery off
!RMA operation
!RMA entry
configure
snmp-server sysname "MACH-AEE300"
!
Sep. 19, 2014-00
To Next Page
