YOKOGAWA Vnet/IP User Manual

  3.Vnet/IPNetworkCongurationwithoutusingInformationNetwork
3-5
TI 30A10A05-01E
n Vnet/IP station IP address
The following table provides the Vnet/IP station IP addresses corresponding to the Vnet/IP
station types. The IP addresses for open communications and control network TCP/IP protocol
communications are recommended for CENTUM.
Table Vnet/IP station IP address
Station RequiredIPaddresses IP address Settingprocedure
HIS, ENG For bus 1 192.168.<dd>.<2×ss> Automatically set by the DIP
switch in Vnet/IP interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
Open communications 192.168.<128+dd>.<129+ss> Manually set from the Windows
operating system, System View
of ENG.
Control bus TCP/IP
communications
172.16.<dd>.<ss>
FCS Single
CPU
For bus 1 192.168.<dd>.<2×ss> Automatically set by the DIP
switch.
For bus 2 192.168.<128+dd>.<2×ss>
Control bus TCP/IP
communications
172.16.<dd>.<ss> Set from either the System View
of ENG for FCS.
Duplexed
CPU
For bus 1(CPU1) 192.168.<dd>.<2×ss> Automatically set by the DIP
switch.
For bus 2(CPU1) 192.168.<128+dd>.<2×ss>
For bus 1(CPU2) 192.168.<dd>.<2×ss+1>
For bus 2(CPU2) 192.168.<128+dd>.<2×ss+1>
Control bus TCP/IP
communications
172.16.<dd>.<ss> Set from either the System View
of ENG for FCS.
PRM For bus 1 192.168.<dd>.<2×ss> Automatically set by the DIP
switch in Vnet/IP interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
Open communications 192.168.<128+dd>.<129+ss> Manually set from the Windows
operating system.
dd: Domain number
ss: Station number
Aug.19,2011-00
