Yokomo GT-4 RTR User Manual

11
GT4 Series parts list
Part # Description Price
SHOE-TYPE TWO SPEED TRANSMISSION
ZE-640S Shoe-Type 2-Speed Transmission 59.50
ZE-671ST Hollow Center Shaft 10.75
ZE-642S 2-Spd 2nd Gear Clutch Housing 19.00
ZE-643SC 2-Spd Clutch Shoes 20.00
ZE-643SA Adjustment Kit 4.75
RACING CLUTCH
ZE-MTC Racing Clutch Set (for SG-shaft engines) 149.50
ZE-600M Engine Mount Set 24.25
ZE-609MP Pressure Plate 10.50
ZE-615M 2-Spd 15T Pinion (1st Gear) 12.00
ZE-616M 2-Spd 16T Pinion (1st Gear) 12.00
ZE-619M 2-Spd 19T Pinion (2nd Gear) 12.00
ZE-620M 2-Spd 20T Pinion (2nd Gear) 12.00
ZE-610M Clutch Bell 16.00
ZE-609M Clutch Shoe 16.00
ZE-609MG Clutch Weights 7.00
ZE-609MC Pre-Load Adjustment Nut & Retainer 12.00
ZE-609MS Clutch Spring, Soft 2.25
ZE-609MH Clutch Spring, Hard 2.25
ZE-609MT Thrust Bearing Shaft 5.50
ZE-603M Clutch Nut 8.25
ZE-604M Flywheel 24.25
TB-105 Thrust Bearing (5x10x4mm) 8.50
ENGINE
ZE-600 Engine Mount Set 28.00
ZE-600C Engine Mount Cap Screws 1.50
ZE-600R Low-CG Aluminum Engine Mounts 25.00
ZE-600RB Low-CG Aluminum Engine Mounts Blue 26.00
ZE-600RTR RTR Engine Mount Set 21.00
ZE-600S M4 Flat Head Screw & Alum Washers 2.50
ZE-603 Clutch Nut Shaft 4.50
ZE-603S Extended Clutch Nut Shaft 3.00
ZE-603W Clutch Nut Shaft Washers 2.50
ZE-604 Flywheel 20.00
ZE-604C Flywheel Collet 5mm7mm 5.00
ZE-604R Low-CG Lightened Flywheel 16.50
ZE-609 Clutch Shoes 7.50
ZE-609S Clutch Springs 2.00
ZE-654 Nylon Tie-wraps 2.50
ZE-655 Silicon Fuel Tubing 4.00
ZE-656 Super Air Filter (Yokomo, OS, Picco) 6.75
EXHAUST
ZE-651 Plastic Tuned Pipe Set 10.50
ZE-651A Tuned Pipe (Polished) 49.75
ZE-651S Tuned Pipe & Manifold Set (Polished) 66.75
ZE-651SC In-line Tuned Pipe Set (Polished) 84.25
ZE-651W Mufer Wire 3.50
ZE-652 Silicon Coupler 3.50
ZE-653 Side Exhaust Manifold (Non Pull-Start) 25.00
ZE-653S Side Exhaust Manifold (For RTR) 25.00
ZE-653G Exhaust Manifold Gasket 3.50
ZE-653R Rear Exhaust Manifold 17.50
ZE-653RG Rear Exhaust Manifold Gasket 6.75
ZE-MMBP MMielke In-line Tuned Pipe (Black) 80.00
ZE-MMPP MMielke In-line Tuned Pipe (Polished) 90.00
RX-18 ENGINE PARTS
ZE-18HS Blue aluminum heat sink (w/screws) 42.00
ZE-18CB Rotary carburetor (Complete) 40.00
ZE-18CS Crankshaft (For pull-start) 36.00
ZE-18EC Engine case (w/bearings) 42.00
ZE-18PS Pull-start unit (Complete) 38.00
ZE-18PC Piston & sleeve set (w/ connecting rod) 40.00
ZE-18PS2 Pull Start Unit (w/o bearing) 18.00
Part # Description Price
SHOCK PARTS
YS-1SSS-4 Plastic Shock Set 1 Pr 14.75
YS-1SS-6 Low-Friction Pro Shocks, Long 1 Pr 31.00
YS-1SS-PRO GT-4PRO Alum. Shock Set Complete 55.00
YS-1SSS-5 Aluminum Shock Set 1 Pr 27.50
YS-4SSS-4 SSS Plastic Shock Body 4 Pk 7.75
YS-4SSS-5 SSS Aluminum Shock Body 7.75
YS-53S-4T Ti Nitride Shock Shafts 4 Pk 20.00
YS-5S-2 Shock Shaft & Piston 3.50
YS-5SSS-1 Shock Shaft 2.00
YS-6W Shock Plastic Parts 1.50
YS-7-1 Shock Maintenance Kit 4.75
YS-7S Soft Shock O-Rings 2.00
YS-8B Shock End Cap Balls 1.75
YS-8Y Shock End Caps 3.00
ZC-732 Setting Spacers 2.25
ZC-732S Setting Spacers 0.3 & 0.5mm 3.50
SHOCK SPRINGS (Listed in order of soft to hard)
YS-1360 Pro Spring, Black 5.25
YS-1355 Pro Spring, Blue 5.25
YS-1465 Pro Spring, White 5.25
YS-1460 Pro Spring, Flourescent Yellow 5.25
YS-14575 Pro Spring, Pink 5.25
YS-1455 Pro Spring, Flourescent Green 5.25
YS-14525 Pro Spring, Stainless 2.00
YS-1450 Pro Spring, Flourescent Orange 5.25
YS-1560 GT-4 Shock Spring Set, Dark Green 4.00
YS-1660 GT-4 Pro Spring, Red 5.25
YS-1655 GT-4 Pro Spring, Yellow 5.25
YS-1650 GT-4 Pro Spring, Green 5.25
YS-1760 GT-4 Shock Spring Set, Polished Silver 5.25
YS-1755 GT-4 Pro Spring, Grey 5.25
YS-1750 GT-4 Pro Spring, Brown 5.25
BRAKES
ZE-630 Brake Disc 3.00
ZE-631 Steel Brake Pad 3.00
ZE-631S Brake Pad Support 3.00
ZE-632 Brake Pad Lining 3.00
ZE-632H High Performance Brake Lining 4.00
ZE-633 Brake Cam 7.00
ZE-634 Brake Pad Pin 3.00
ZE-635 Brake Disc Pin 4.00
ZE-630S Fiberglass Brake Disc 3.00
GREASE, LUBRICANTS & OILS
CS-DGH Gear Diff Grease, Hard (100,000wt) 4.50
CS-DGM Gear Diff Grease, Med (50,000wt) 4.50
CS-SBG Black Grease 2.50
YS-3S Super Blend Shock Oil #150 / #200 9.80
YS-3M Super Blend Shock Oil #250 / #300 9.80
YS-3H Super Blend Shock Oil #350 / #400 9.80
YS-3EH Super Blend Shock Oil #450 / #500 9.80
YS-3SH Super Blend Shock Oil #550 / #600 9.80
YS-3UH Super Blend Shock Oil #650 / #700 9.80
BEARINGS
BB-105-2 5x10mm Bearing (Clutch Bell) 9.50
BB-126-2 6x12mm Bearing (Layshaft) 9.50
BB-1510T 10x15mm Teon Bearing (Axle, Diff) 16.50
BB1510 10x15mm Precision Bearing (Axle, Diff) 11.75
