1. The receiver can be controlled by max. 10 transmitters.
2. A break between succesive button presses longer than 6 seconds, will automatically cause the exit from programming
mode without saving the changes.
9. Programming of the next transmitter
METHOD NO. 1:
6. Programming of the first transmitter
4
1. A break between succesive button presses longer than 6 seconds, will automatically cause the exit from programming
mode without saving the changes.
7. Changing the direction of motor operation
8. Limit positions adjustment
The motor will make a
sound. The blind will make
short up/down moves.
Press and hold STOP
button on the remote
control for 2 sec.
The blind will make two
short up/down moves. The
motor will make a few short
sound signals.
DOWN button controls
lifting of the blind.
Press and hold
UP and DOWN buttons
for 2 seconds.
The blind will make
short up/down moves.
DOWN button controls
lowering the blind.
Press P2 programming button
on remote control A.
Remote control
has been programmed.
The motor will make
a sound. The blind
will make short
up/down moves.
The motor will make
a sound. The blind
will make short
up/down moves.
The blind will make two short
up/down moves. The motor
will make a few short sound
signals.
Press P2
programming
button on remote
control A.
Press P2
programming
button on remote
control B.
Turn on power supply.
You must adjust limit positions manually, with a regulator from your set.
Decreasing the range
Increasing the range
Direction of engine rotation
Direction of adjustment of
the limit switch
To adjust lower or upper limit position, put the blind in motion of
closing or opening, until it stops in a factory set position. To
increase this range, use the proper knob and move it towards „+”.
If the range is too big, decrease it by moving it towards „-”.
