York AC036X1222 User Manual

036-21106-005 Rev. B (0505)
10 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. AC018X1222
INDOOR COIL MODEL NO. G1FA024S14,17
CONDENSING|
ENTERING AIR
TEMPERATURE
IDCFM 500 650 800
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75
T.C. 20.1 19.3 18.2 20.1 19.4 18.6 20.1 19.5 18.9
S.C. 11.711.511.312.112.212.212.512.813.1
KW 1.26 1.25 1.25 1.27 1.26 1.26 1.27 1.26 1.26
85
T.C. 19.8 18.7 17.0 20.0 19.1 17.7 20.3 19.5 18.3
S.C. 11.711.410.912.712.512.113.613.513.4
KW 1.37 1.35 1.34 1.37 1.36 1.35 1.38 1.37 1.36
95
T.C. 19.5 18.1 15.8 20.0 19.2 16.7 20.5 19.5 17.7
S.C. 11.711.310.413.213.012.014.714.213.6
KW 1.47 1.45 1.43 1.48 1.47 1.45 1.49 1.48 1.46
105
T.C. 18.1 16.3 14.2 18.7 17.1 15.0 19.4 17.8 15.8
S.C. 11.3 10.6 9.7 13.0 12.2 11.3 14.7 13.8 12.9
KW 1.58 1.55 1.52 1.59 1.57 2.53 1.61 1.58 3.54
115
T.C. 16.6 14.5 12.7 17.5 15.3 13.2 18.3 16.1 13.8
S.C. 10.8 9.8 9.1 12.7 11.6 10.6 14.7 13.4 12.1
KW 1.69 1.65 1.61 1.71 1.67 3.62 1.73 1.69 5.62
125
T.C. 15.2 12.7 11.1 16.2 13.6 11.5 17.3 14.5 11.9
S.C. 10.4 9.1 8.4 12.5 11.1 9.9 14.6 13.0 11.4
KW 1.79 1.75 1.70 1.82 1.77 4.70 1.85 1.79 7.70
NOTE:
ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
F2RC/F2FC024 1.04 1.17 1.01
F2RP/F2FP024 1.04 1.04 1.01
N1AHB0806 G2FD024(S,H)14,17 1.02 1.02 1.00
G1HD024 1.04 1.04 1.01
G1NA030S17K 1.04 1.04 1.01
G1NA030S21M 1.04 1.17 1.01
G1UA024S14,17 1.00 1.00 1.00
G2FD024(S,H)14,17 1.02 1.02 1.00
G2FD030(S,H)17 1.04 1.04 1.01
