Part list
YORK REF. REF. DESCRIPTION QTY.
52047-1 A CONSOLE 1
52047-2 A-1 SCREW (M5 X 10) 4
52047-3 B FRONT HANDELBAR 1
52047-4 B-1 SCREW (M3 X 20L) 2
52047-5 B-2 FOAM GRIP 2
52047-6 B-3 HAND PULSE SENSOR 2
52047-7 B-4 HAND PULSE SENSOR WIRE 1
52047-8 B-5 SENSOR WIRE, UPPER 1
52047-9 B-6 HEX HEAD SCREW (M8 X P1.25 X 16L) 3
52047-10 B-7 SEMI-CIRCULAR WASHER (Ø8 X Ø19 X 2T) 3
52047-11 B-8 END CAP 2
52047-12 B-9 UPPER HANDLEBAR SET 2
52047-13 B-10 FOAM GRIP 2
52047-14 B-11 UPPER HANDLEBAR 2
52047-15 B-12 END CAP 2
52047-16 C-1 HANDLEBAR POST 1
52047-17 C-2 TENSION CONTROLLER, UPPER 1
52047-18 C-3 CURVED WASHER (Ø17.5 X Ø25 X 0.3T) 2
52047-19 C-4 FLAT WASHER (Ø10 X Ø26 X 2T) 2
52047-20 C-5 NYLOC SCREW (M8 X P1.0 X 20L) 2
52047-21 C-6 LOWER HANDLEBAR 2
52047-22 C-7 SPRING WASHER(Ø8.1 X Ø12.9 X 2.4T) 4
52047-23 C-8 SEMI-CIRCULAR WASHER 4
52047-24 C-9 HEX HEAD SCREW (M8 X P1.25 X 16L) 4
52047-25 C-10 SENSOR WIRE, LOWER 1
52047-26 D-R PEDAL ARM, RIGHT 1
52047-27 D-L PEDAL ARM, LEFT 1
52047-28 D-1R/L PEDAL, PAIR 2
52047-29 D-2 NYLON NUT (9/16” X 6T) 1
52047-30 D-3 C-CLIP (Ø17) 4
52047-31 D-4 FLAT WASHER (Ø17.5 X Ø25 X 0.3T) 2
52047-32 D-5 CRANK PIN, LEFT 1
52047-33 D-6 CRANK PIN, RIGHT 1
52047-34 D-7 END CAP 2
52047-35 D-8 NYLON NUT (9/16” X 6T) 1
52047-36 E FRAME 1
52047-37 E-1 SENSOR HOLDER 1
52047-38 E-2 SCREW (M4 X 10L) 1
52047-39 E-3 C-CLIP (Ø20) 1
52047-40 E-4 CURVED WASHER (Ø20 X Ø30 X 0.3T) 1
52047-41 E-5 FLAT WASHER (Ø20.3 X Ø30 X 1T) 1
52047-42 E-6 BEARING (6004RS PLASTIC) 2
52047-43 E-7 DRIVE PULLEY 1
52047-44 E-8 BUSHING (Ø20.5 X Ø25 X 7.5MM) 1
52047-45 E-9 AXLE 1
YORK REF. REF. DESCRIPTION QTY.
52047-46 E-10 HEX SCREW (M8 X P1.25 X 12L X 5T) 3
52047-47 E-11 DRIVE BELT 1
52047-48 E-12 CRANK, RIGHT 1
52047-49 E-13 PATTERN NUT (M10 X P1.25 X 10T) 2
52047-50 E-14 SIDE COVER, RIGHT 1
52047-51 E-15 SCREW (3/16” X 3/4”) 6
52047-52 E-16 SIDE COVER, LEFT 1
52047-53 E-17 SCREW (M4 X 50L) 5
52047-54 E-18 CRANK, LEFT 1
52047-55 E-19 TENSION CONTROLLER, LOWER 1
52047-56 E-20 SPEED SENSOR 1
52047-57 F HARDWARE PACK (F-1~F-11) 1
52047-58 F-1 SEMI-CIRCULAR WASHER (Ø8 X Ø19 X 2T) 8
52047-59 F-2 ACRON NUT (M8) 10
52047-60 F-3 CARRIAGE BOLT (M8 X P1.25 X 35L) 4
52047-61 F-4 SCREW COVER 2
52047-62 F-5 HEX HEAD SCREW (M6 X P1.0 X 40L) 6
52047-63 F-6 FLAT WASHER (Ø6 X Ø16 X 2T) 6
52047-64 F-7 LOCKING KNOB 6
52047-65 F-8 SPRING WASHER (Ø6) 6
52047-66 F-9 FLAT WASHER (Ø8 X Ø16 X 1T) 2
52047-67 F-10 HEX HEAD SCREW (M8 X P1.25 X 45L) 2
52047-68 F-11 CARRIAGE BOLT (M8 X P1.25 X 75L) 4
52047-69 G MAGNET BRACKET (G-1~G-6) 1
52047-70 G-1 HEX SCREW (M6 X P1.0 X 16L) 2
52047-71 G-2 SPRING WASHER (Ø6) 2
52047-72 G-3 FLAT WASHER (Ø6 X Ø13 X 1T) 2
52047-73 G-4 C-CLIP (Ø12) 2
52047-74 G-5 CURVED WASHER (Ø12.5 X Ø18 X 0.3T) 2
52047-75 G-6 SPRING (Ø12 X Ø1.4 X 9T) 1
52047-76 H FLYWHEEL SET 1
52047-77 H-1 NUT (3/8” X -26 X 4.5T) 3
52047-78 H-2 PATTERN NUT (3/8” X -26 X 7T) 2
52047-79 H-3 FLYWHEEL AXLE 1
52047-80 H-4 FLAT WASHER (Ø10 X Ø14 X 1T) 1
52047-81 H-5 BEARING (6000RS PLASTIC) 1
52047-82 H-6 BEARING (6300RS PLASTIC) 1
52047-83 H-8 BUSHING (Ø10 X Ø14 X 6MM) 1
52047-84 I-1 REAR STABILIZER END CAP 2
52047-85 I-2 REAR STABILIZER 2
52047-86 J-1 END CAP W/ TRANSPORT WHEEL 2
52047-87 J-2 SCREW (M3 X 8) 2
52047-88 J-3 FRONT STABILIZER 1
52047-89 FIXING BLISTER PACK 1
