York Active 110 - Care & Maintenance; Assembly Instructions

www.yorkfitness.com
www.yorkfitness.com
5
Assembly instructions
F10
x 2
ALLEN BOLT
(M8 X P1.25 X 45MM)
F1
x 8
CURVED WASHER
(Ø8 X Ø19 X 2T)
F11
x 4
CARRIAGE BOLT
(M8 X P1.25 X 75MM)
F3
x 4
CARRIAGE BOLT
(M8 X P1.25 X 35MM)
F2
x 10
ACORN NUT
(M8)
F7
x 6
F4
x 2
F9
x 2
REGULAR WASHER
(Ø8 X Ø16 X 1T)
SCREWDRIVER
BOX SPANNER
ALLEN KEY
ALLEN KEY
WRENCH
F5
x 6
ALLEN BOLT
(M6 X 40MM)
F6
x 6
FLAT WASHER
(Ø6 X Ø16 X 2T)
F8
x 6
SPRING WASHER
(Ø6)
• Prepare your work area-Itisimportantyouassembletheproductinacleanandunclutteredspace.
• Work with a friend-Werecommendyouhavesomeoneassistyouwiththeassemblyas
someofthecomponentsarequiteheavy.
• Open the carton -Checkanywarningsonthecartonandmakesureyouhaveittherightwayup.
• Unpack the carton-Removeallthepartsandlaythemoutontheoor.
Make sure you have the following parts:
Care & Maintenance
• This equipment should not be placed outdoors, in a garage or an outbuilding. Keep the
equipment in a dry place with as little temperature variation as possible.
• We recommend placing a mat beneath the equipment to protect both the equipment and
your flooring.
• Alwaysplacetheequipmentinadryenvironment.
• Useawarm,dampclothtokeeptheproductclean.
• Nowetcleaningofelectricalcomponents.Unplugbeforeanycareandmaintenance.
• Thesafetyleveloftheequipmentcanbemaintainedonlyifitisregularlyexaminedfor
damageandwear.Thisincludesanyropes,pulleys,nuts,bolts,movingparts,bushes,
chains,wheels,bearings&connectionpointsetc.
• Ensurethatyouinspecttheproductregularly-atleastonceaweekisrecommended.
• Ensurethatallxingsaretightbeforeuse.
• Alwaysreplacedamaged/worncomponentswithoriginalpartsfromthemanufacturer.
