Johnson Controls Unitary Products 11
Capacity Performance
DEZ024-060 Cooling Capacities
DEZ024 (2.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 30.3 1.2 8.6 6.3 4.0 - - - 28.6 1.6 10.7 8.3 6.0 - - -
72 28.5 1.4 15.0 12.7 10.4 8.1 - - 26.4 1.7 15.6 13.2 10.9 8.5 - -
67 26.6 1.6 21.4 19.1 16.8 14.5 12.2 - 24.2 1.8 20.5 18.1 15.8 13.5 11.1 -
62 24.1 1.4 23.8 19.1 16.2 13.9 11.6 9.3 21.8 1.6 21.7 19.3 17.0 14.6 12.3 9.9
57 23.5 1.4 23.5 20.1 17.6 15.3 13.0 10.7 21.8 1.6 21.8 20.1 17.8 15.4 13.1 10.7
700
77 31.8 1.3 10.5 7.7 5.2 - - - 30.0 1.6 12.4 9.6 7.0 - - -
72 29.8 1.5 17.9 15.4 12.9 10.4 - - 27.7 1.7 18.0 15.4 12.7 10.1 - -
67 27.9 1.7 25.4 23.1 20.6 18.1 15.6 - 25.4 1.8 23.6 21.1 18.5 15.9 13.2 -
62 25.3 1.5 25.1 22.8 20.1 17.6 15.1 12.6 22.9 1.7 22.9 21.7 19.9 17.2 14.6 12.0
57 24.7 1.5 24.7 23.0 21.7 19.2 16.7 14.2 22.9 1.7 22.9 22.1 20.8 18.2 15.5 12.9
800
77 33.2 1.4 12.4 9.1 6.3 - - - 31.5 1.7 14.1 10.9 8.0 - - -
72 31.2 1.6 20.8 18.1 15.4 12.7 - - 29.1 1.8 20.4 17.5 14.6 11.7 - -
67 29.2 1.8 29.2 27.1 24.4 21.7 19.0 - 26.7 1.9 26.7 24.1 21.2 18.3 15.4 -
62 26.4 1.6 26.4 26.4 24.0 21.3 18.6 15.9 24.0 1.7 24.0 24.0 22.7 19.8 17.0 14.1
57 25.8 1.6 25.8 25.8 25.8 23.1 20.4 17.7 24.1 1.7 24.1 24.1 23.8 20.9 18.0 15.1
900
72 31.8 1.8 21.0 17.8 14.6 11.4 - - 29.4 1.9 21.1 17.8 14.6 11.3 - -
67 29.7 2.0 29.7 26.6 23.4 20.3 17.1 - 27.0 2.0 27.0 24.4 21.2 17.9 14.7 -
62 26.9 1.7 26.9 26.9 23.9 20.7 17.5 14.3 24.3 1.8 24.3 24.3 22.7 19.5 16.2 13.0
57 26.3 1.7 26.3 26.3 25.5 22.3 19.1 16.0 24.3 1.8 24.3 24.3 23.8 20.5 17.3 14.0
1000
72 32.4 1.9 21.2 17.5 13.9 10.2 - - 29.7 2.0 21.8 18.2 14.6 11.0 - -
67 30.3 2.1 30.3 26.1 22.5 18.8 15.2 - 27.2 2.1 27.2 24.8 21.2 17.6 13.9 -
62 27.4 1.9 27.4 27.4 23.7 20.1 16.4 12.8 24.6 1.9 24.6 24.6 22.7 19.1 15.5 11.9
57 26.8 1.9 26.8 26.8 25.2 21.5 17.9 14.2 24.6 1.9 24.6 24.6 23.8 20.2 16.6 12.9
95°F 105°F
600
77 26.8 2.0 12.8 10.4 8.0 - - - 24.6 2.1 12.5 9.6 7.2 - - -
72 24.3 1.9 16.2 13.8 11.4 9.0 - - 21.9 2.1 15.3 12.9 10.5 8.0 - -
67 21.8 1.9 19.6 17.2 14.8 12.4 10.0 - 19.2 2.0 18.1 16.2 13.8 11.3 8.9 -
62 19.5 1.9 19.5 19.5 17.7 15.3 12.9 10.5 18.3 2.0 18.3 18.3 16.3 13.8 11.4 9.0
57 20.1 1.9 20.1 20.1 17.9 15.6 13.2 10.8 18.6 2.0 18.6 18.5 16.2 13.7 11.3 8.9
700
77 28.3 1.9 14.3 11.6 8.8 - - - 25.5 2.1 14.7 10.9 7.9 - - -
72 25.6 1.9 18.1 15.3 12.6 9.9 - - 22.7 2.1 17.0 14.3 11.5 8.7 - -
67 22.9 1.9 21.8 19.1 16.3 13.6 10.9 - 19.9 2.0 19.3 17.6 15.1 12.4 9.6 -
62 20.6 1.9 20.6 20.6 19.6 16.9 14.1 11.4 18.9 2.0 18.9 18.9 17.9 15.1 12.4 9.6
57 21.2 1.9 21.2 21.2 19.9 17.1 14.4 11.7 19.3 2.0 19.3 19.2 17.8 15.0 12.3 9.5
800
77 29.7 1.9 15.8 12.8 9.7 - - - 26.4 2.1 16.9 12.3 8.6 - - -
72 26.9 1.9 20.0 16.9 13.8 10.7 - - 23.5 2.1 18.8 15.7 12.5 9.4 - -
67 24.1 1.9 24.1 21.0 17.9 14.8 11.8 - 20.6 2.0 20.6 19.1 16.5 13.4 10.3 -
62 21.6 1.9 21.6 21.6 21.5 18.4 15.3 12.3 19.6 2.0 19.6 19.6 19.5 16.4 13.3 10.2
57 22.3 1.9 22.3 22.3 21.8 18.7 15.6 12.6 19.9 2.0 19.9 19.9 19.4 16.3 13.2 10.1
900
72 27.0 2.0 21.2 17.9 14.6 11.2 - - 23.9 2.1 20.1 16.7 13.3 10.0 - -
67 24.2 2.0 24.1 22.2 18.9 15.6 12.2 - 20.9 2.1 20.9 19.9 17.6 14.2 10.8 -
62 21.7 1.9 21.7 21.7 21.6 18.3 15.0 11.7 19.9 2.1 19.9 19.9 19.9 16.5 13.1 9.7
57 22.3 1.9 22.3 22.3 22.1 18.8 15.4 12.1 20.3 2.1 20.3 20.3 20.0 16.6 13.2 9.8
1000
72 27.0 2.1 22.5 18.9 15.3 11.7 - - 24.2 2.2 21.4 17.8 14.1 10.5 - -
67 24.2 2.1 24.2 23.4 19.9 16.3 12.7 - 21.2 2.2 21.2 20.8 18.6 14.9 11.3 -
62 21.8 2.0 21.8 21.8 21.8 18.2 14.6 11.0 20.2 2.2 20.2 20.2 20.2 16.6 12.9 9.3
57 22.4 2.0 22.4 22.4 22.4 18.8 15.2 11.7 20.6 2.2 20.6 20.6 20.6 16.9 13.3 9.6
