York AFFINITY DEZ024 - Electrical Data and Specifications

294604-YTG-G-0511
Johnson Controls Unitary Products 49
Electrical Data
DEZ024-060 Cooling Only With/Without Electric Heat
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA Model kW Stages Amps
024
(2.0)
208/230-1-60 8.3 43 13 1.3 4.1
None - - - 15.8 20
2NH04500506 3.8 / 5 1 18.1 / 20.8 27.7 / 31.2 30 / 35
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 39 / 44.2 40 / 45
2NH04501006 7.5 / 10 2 36.1 / 41.7 50.3 / 57.2 60 / 60
030
(2.5)
208/230-1-60 13.1 74 21 1.3 4.1
None - - - 21.8 30
2NH04500506 3.8 / 5 1 18.1 / 20.8 27.7 / 31.2 30 / 35
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 39 / 44.2 40 / 45
2NH04501006 7.5 / 10 2 36.1 / 41.7 50.3 / 57.2 60 / 60
2NH04501506 11.3 / 15 2 54.2 / 62.5 72.8 / 83.3 80 / 90
036
(3.0)
208/230-1-60 14.7 74 23 1.3 4.1
None - - - 23.8 30
2NH04500506 3.8 / 5 1 18.1 / 20.8 27.7 / 31.2 35 / 35
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 39 / 44.2 40 / 45
2NH04501006 7.5 / 10 2 36.1 / 41.7 50.3 / 57.2 60 / 60
2NH04501506 11.3 / 15 2 54.2 / 62.5 72.8 / 83.3 80 / 90
208/230-3-60 9.1 68 14 1.3 4.1
None - - - 16.8 25
2NH04501025 7.5 / 10 1 20.8 / 24.1 31.2 / 35.2 35 / 40
2NH04501525 11.3 / 15 1 31.3 / 36.1 44.2 / 50.2 45 / 60
460-3-60 4.5 34 7 0.8 4.1
None - - - 10.5 15
2NH04501046 10 1 12 20.2 25
2NH04501546 15 1 18 27.7 30
575-3-60 3.8 28 6 0.6 6.0
None - - - 11.9 15
2NH04501058 10 1 9.6 19.5 20
2NH04501558 15 1 14.4 25.5 30
042
(3.5)
208/230-1-60 15.7 88 25 1.7 6.0
None - - - 27.3 35
2NH04500506 3.8 / 5 1 18.1 / 20.8 30.1 / 33.5 40 / 40
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 41.4 / 46.6 45 / 50
2NH04501006 7.5 / 10 2 36.1 / 41.7 52.6 / 59.6 60 / 60
2NH04501506 11.3 / 15 2 54.2 / 62.5 75.2 / 85.6 80 / 90
208/230-3-60 9.3 68 15 1.7 6.0
None - - - 19.3 25
2NH04501025 7.5 / 10 1 20.8 / 24.1 33.6 / 37.6 35 / 40
2NH04501525 11.3 / 15 1 31.3 / 36.1 46.6 / 52.6 50 / 60
460-3-60 5.1 34 8 1.0 6.0
None - - - 13.6 15
2NH04501046 10 1 12 22.5 25
2NH04501546 15 1 18 30.1 35
575-3-60 3.8 28 6 0.8 6.0
None - - - 12.1 15
2NH04501058 10 1 9.6 19.5 20
2NH04501558 15 1 14.4 25.5 30
048
(4.0)
208/230-1-60 16.8 115 25 1.7 6.0
None - - - 28.7 35
2NH04501006 7.5 / 10 2 36.1 / 41.7 52.6 / 59.6 60 / 60
2NH04501506 11.3 / 15 2 54.2 / 62.5 75.2 / 85.6 80 / 90
2NH04502006 15 / 20 2 72.2 / 83.3 97.8 / 111.7 100 / 125
2NH04502506 18.8 / 25 2 90.3 / 104.2 120.3 / 137.7 125 / 150
208/230-3-60 11.2 120 18 1.7 6.0
None - - - 21.7 30
2NH04501025 7.5 / 10 1 20.8 / 24.1 33.6 / 37.6 35 / 40
2NH04501525 11.3 / 15 1 31.3 / 36.1 46.6 / 52.6 50 / 60
2NH04502025 15 / 20 2 41.7 / 48.1 59.6 / 67.6 60 / 70
2NH04502525 18.8 / 25 2 52.1 / 60.1 72.7 / 82.7 80 / 90
460-3-60 5.1 50 8 1.0 6.0
None - - - 13.6 15
2NH04501046 10 1 12 22.5 25
2NH04501546 15 1 18 30.1 35
2NH04502046 20 2 24.1 37.6 40
2NH04502546 25 2 30.1 45.1 50
575-3-60 4.5 40 7 0.8 6.0
None - - - 12.8 15
2NH04501058 10 1 9.6 19.5 20
2NH04501558 15 1 14.4 25.5 30
2NH04502058 20 2 19.2 31.6 35
2NH04502558 25 2 24.1 37.6 40
