294604-YTG-G-0511
Johnson Controls Unitary Products 13
DEZ030 (2.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
750
77 35.0 2.5 16.1 13.5 11.0 - - - 33.8 2.7 15.7 13.0 10.4 - - -
72 33.6 2.4 20.8 18.2 15.6 13.1 - - 31.9 2.6 20.2 17.5 14.9 12.2 - -
67 32.2 2.4 25.5 22.9 20.3 17.8 15.2 - 30.0 2.6 24.6 22.0 19.4 16.7 14.1 -
62 29.9 2.4 29.9 26.9 24.3 21.7 19.2 16.6 27.5 2.5 27.5 25.9 23.3 20.6 18.0 15.3
57 29.9 2.4 29.9 29.9 28.1 25.6 23.0 20.4 27.8 2.5 27.8 27.8 25.9 23.3 20.6 18.0
875
77 35.9 2.5 17.4 14.5 11.6 - - - 34.8 2.7 17.1 14.1 11.1 - - -
72 34.5 2.4 22.4 19.5 16.6 13.7 - - 32.9 2.6 21.9 18.9 15.9 12.9 - -
67 33.1 2.4 27.4 24.5 21.6 18.7 15.8 - 30.9 2.6 26.7 23.7 20.7 17.7 14.8 -
62 30.7 2.4 30.7 29.2 25.8 22.9 20.0 17.2 28.4 2.5 28.4 27.6 24.9 21.9 18.9 15.9
57 30.7 2.3 30.7 30.7 29.9 27.0 24.1 21.2 28.6 2.5 28.6 28.6 27.7 24.7 21.8 18.8
1000
77 36.8 2.4 18.7 15.5 12.3 - - - 35.9 2.7 18.4 15.1 11.8 - - -
72 35.4 2.4 24.0 20.8 17.6 14.4 - - 33.9 2.6 23.6 20.2 16.9 13.6 - -
67 34.0 2.4 29.3 26.1 22.9 19.7 16.5 - 31.9 2.6 28.7 25.4 22.0 18.7 15.4 -
62 31.5 2.3 31.5 31.5 27.3 24.1 20.9 17.7 29.2 2.5 29.2 29.2 26.5 23.2 19.9 16.6
57 31.5 2.3 31.5 31.5 31.5 28.5 25.3 22.0 29.5 2.5 29.5 29.5 29.5 26.2 22.9 19.6
1125
72 35.9 2.5 25.0 21.7 18.3 15.0 - - 34.2 2.7 24.6 21.1 17.6 14.2 - -
67 34.4 2.4 30.8 27.2 23.8 20.5 17.2 - 32.2 2.6 29.9 26.4 23.0 19.5 16.0 -
62 31.9 2.4 31.9 31.9 28.7 25.4 22.0 18.7 29.5 2.6 29.5 29.5 27.6 24.1 20.6 17.2
57 32.0 2.4 32.0 32.0 32.0 28.7 25.3 22.0 29.8 2.6 29.8 29.8 29.8 26.3 22.9 19.4
1250
72 36.4 2.5 26.0 22.6 19.1 15.6 - - 34.6 2.7 25.6 22.0 18.4 14.7 - -
67 34.9 2.5 32.2 28.3 24.8 21.3 17.8 - 32.5 2.7 31.2 27.5 23.9 20.2 16.6 -
62 32.4 2.4 32.4 32.4 30.1 26.6 23.2 19.7 29.8 2.6 29.8 29.8 28.7 25.1 21.4 17.8
57 32.4 2.4 32.4 32.4 32.4 28.9 25.4 22.0 30.1 2.6 30.1 30.1 30.1 26.5 22.8 19.2
95°F 105°F
750
77 32.5 2.9 15.2 12.5 9.8 - - - 30.8 3.1 14.8 12.0 9.2 - - -
72 30.1 2.8 19.5 16.8 14.1 11.4 - - 27.9 3.0 18.9 16.1 13.3 10.5 - -
67 27.7 2.8 23.8 21.1 18.4 15.7 12.9 - 25.1 2.9 23.1 20.3 17.5 14.7 11.9 -
62 25.1 2.7 25.1 24.9 22.2 19.5 16.8 14.1 22.7 2.9 22.7 22.6 20.3 17.5 14.7 11.9
57 25.6 2.7 25.6 25.6 23.7 21.0 18.3 15.5 23.8 2.9 23.8 23.8 21.8 19.0 16.2 13.4
875
77 33.7 2.9 16.7 13.6 10.6 - - - 31.5 3.1 16.7 12.9 9.8 - - -
72 31.2 2.8 21.3 18.3 15.2 12.1 - - 28.6 3.0 20.5 17.4 14.2 11.1 - -
67 28.8 2.8 25.9 22.9 19.8 16.7 13.7 - 25.8 2.9 24.3 21.8 18.7 15.6 12.4 -
62 26.0 2.7 26.0 25.9 23.9 20.9 17.8 14.7 23.3 2.9 23.3 23.2 21.8 18.6 15.5 12.3
57 26.6 2.7 26.6 26.6 25.5 22.5 19.4 16.3 24.4 2.9 24.4 24.4 23.3 20.2 17.1 13.9
1000
77 34.9 2.9 18.1 14.7 11.3 - - - 32.3 3.1 18.7 13.9 10.4 - - -
72 32.4 2.8 23.1 19.7 16.3 12.9 - - 29.3 3.0 22.1 18.7 15.2 11.7 - -
67 29.8 2.7 28.0 24.6 21.2 17.8 14.4 - 26.4 2.9 25.5 23.4 19.9 16.4 13.0 -
62 27.0 2.7 27.0 27.0 25.6 22.2 18.8 15.4 23.8 2.9 23.8 23.8 23.2 19.7 16.2 12.8
57 27.5 2.7 27.5 27.5 27.4 24.0 20.5 17.1 25.0 2.9 25.0 25.0 24.9 21.4 17.9 14.5
1125
72 32.5 2.9 24.2 20.6 16.9 13.3 - - 29.8 3.0 23.4 19.7 16.0 12.3 - -
67 29.9 2.8 29.1 25.7 22.1 18.5 14.9 - 26.8 3.0 26.4 24.5 21.0 17.2 13.5 -
62 27.1 2.7 27.1 27.1 26.5 22.9 19.2 15.6 24.2 2.9 24.2 24.2 23.9 20.2 16.5 12.8
57 27.7 2.7 27.7 27.7 27.6 24.0 20.4 16.8 25.4 2.9 25.4 25.4 25.3 21.6 17.9 14.2
1250
72 32.7 2.9 25.3 21.4 17.6 13.8 - - 30.3 3.1 24.7 20.7 16.8 12.8 - -
67 30.1 2.8 30.1 26.8 23.0 19.2 15.3 - 27.2 3.0 27.2 25.6 22.0 18.1 14.1 -
62 27.3 2.8 27.3 27.3 27.3 23.5 19.6 15.8 24.6 3.0 24.6 24.6 24.6 20.7 16.7 12.7
57 27.8 2.8 27.8 27.8 27.8 24.0 20.2 16.4 25.8 3.0 25.8 25.8 25.8 21.9 17.9 13.9
To Next Page
