18 Johnson Controls Unitary Products
115°F 125°F
1050
77 37.8 4.2 21.3 15.2 10.9 - - - 34.0 4.4 22.8 14.3 9.8 - - -
72 33.1 4.0 24.9 20.6 16.3 12.0 - - 29.0 4.3 23.4 19.1 14.9 10.6 - -
67 28.4 3.9 28.4 26.0 21.7 17.4 13.1 - 24.0 4.1 24.0 24.0 20.0 15.7 11.5 -
62 26.8 3.9 26.8 26.8 24.1 19.8 15.5 11.2 23.5 4.1 23.5 23.5 21.0 16.7 12.4 8.1
57 26.5 3.9 26.5 26.5 23.9 19.6 15.3 11.0 23.4 4.1 23.4 23.4 20.9 16.6 12.4 8.1
1225
77 40.2 4.2 26.4 17.7 12.2 - - - 36.3 4.5 28.0 18.1 11.1 - - -
72 35.2 4.1 28.3 23.3 18.3 13.3 - - 30.9 4.3 26.8 21.8 16.9 11.9 - -
67 30.2 4.0 30.2 29.0 24.4 19.4 14.4 - 25.6 4.2 25.6 25.6 22.7 17.7 12.7 -
62 28.4 3.9 28.4 28.4 27.1 22.1 17.1 12.2 25.0 4.1 25.0 25.0 23.8 18.8 13.8 8.9
57 28.2 3.9 28.2 28.2 26.8 21.9 16.9 11.9 25.0 4.2 25.0 25.0 23.7 18.7 13.8 8.8
1400
77 42.5 4.2 31.5 20.1 13.6 - - - 38.5 4.5 33.2 21.8 12.4 - - -
72 37.2 4.1 31.7 26.0 20.3 14.7 - - 32.9 4.4 30.2 24.5 18.9 13.2 - -
67 31.9 4.0 31.9 31.9 27.1 21.4 15.7 - 27.2 4.2 27.2 27.2 25.3 19.6 14.0 -
62 30.1 4.0 30.1 30.1 30.1 24.4 18.7 13.1 26.6 4.2 26.6 26.6 26.6 20.9 15.2 9.6
57 29.8 4.0 29.8 29.8 29.8 24.1 18.4 12.8 26.5 4.2 26.5 26.5 26.5 20.8 15.2 9.5
1550
72 37.2 4.2 33.9 27.7 21.5 15.3 - - 32.9 4.5 32.5 26.3 20.1 13.8 - -
67 31.9 4.1 31.9 31.9 28.7 22.5 16.3 - 27.2 4.3 27.2 27.2 26.9 20.7 14.4 -
62 30.1 4.1 30.1 30.1 30.1 23.9 17.7 11.5 26.6 4.3 26.6 26.6 26.6 20.4 14.1 7.9
57 29.8 4.1 29.8 29.8 29.8 23.6 17.4 11.2 26.5 4.3 26.5 26.5 26.5 20.3 14.0 7.8
1700
72 37.2 4.3 36.2 29.4 22.7 16.0 - - 32.9 4.6 32.9 28.1 21.3 14.4 - -
67 31.9 4.2 31.9 31.9 30.2 23.5 16.8 - 27.2 4.5 27.2 27.2 27.2 21.7 14.9 -
62 30.1 4.2 30.1 30.1 30.1 23.4 16.6 9.9 26.6 4.4 26.6 26.6 26.6 19.8 13.0 6.2
57 29.8 4.2 29.8 29.8 29.8 23.1 16.3 9.6 26.5 4.4 26.5 26.5 26.5 19.7 12.9 6.1
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
DEZ042 (3.5 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
To Next Page
