294604-YTG-G-0511
Johnson Controls Unitary Products 21
DEZ060 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1500
77 78.1 4.6 35.6 29.7 23.9 - - - 73.3 5.1 33.8 27.9 22.1 - - -
72 71.7 4.5 44.2 38.3 32.4 26.5 - - 67.0 5.0 42.2 36.3 30.5 24.7 - -
67 65.2 4.4 52.7 46.8 40.9 35.0 29.1 - 60.6 4.8 50.6 44.7 38.9 33.1 27.3 -
62 58.7 4.3 58.7 56.0 49.4 43.5 37.6 31.7 54.7 4.7 54.7 53.4 47.5 41.7 35.9 30.1
57 51.3 4.2 51.3 51.3 50.1 44.2 38.3 32.5 50.3 4.7 50.3 50.3 48.7 42.9 37.1 31.3
1550
77 78.7 4.6 36.6 30.5 24.4 - - - 74.0 5.1 34.6 28.7 22.7 - - -
72 72.2 4.5 45.3 39.2 33.1 27.1 - - 67.6 4.9 43.3 37.3 31.3 25.4 - -
67 65.7 4.3 54.0 47.9 41.9 35.8 29.7 - 61.3 4.8 51.9 45.9 40.0 34.0 28.0 -
62 59.1 4.2 59.1 57.8 50.5 44.5 38.4 32.3 55.2 4.7 55.2 54.6 48.8 42.8 36.9 30.9
57 51.6 4.2 51.6 51.6 51.3 45.2 39.1 33.1 50.8 4.6 50.8 50.8 50.0 44.1 38.1 32.1
1600
77 79.3 4.6 37.5 31.2 25.0 - - - 74.7 5.1 35.5 29.4 23.3 - - -
72 72.7 4.5 46.4 40.2 33.9 27.7 - - 68.3 4.9 44.4 38.2 32.1 26.0 - -
67 66.2 4.3 55.3 49.1 42.8 36.6 30.3 - 61.9 4.8 53.2 47.1 41.0 34.9 28.8 -
62 59.6 4.2 59.6 59.6 51.7 45.4 39.2 32.9 55.8 4.7 55.8 55.8 50.1 44.0 37.9 31.8
57 52.0 4.1 52.0 52.0 52.0 46.2 40.0 33.7 51.3 4.6 51.3 51.3 51.3 45.2 39.1 33.0
1800
72 74.1 4.6 49.1 42.4 35.6 28.9 - - 69.3 5.1 47.0 40.3 33.7 27.0 - -
67 67.5 4.5 58.5 51.8 45.0 38.3 31.5 - 62.8 4.9 56.3 49.6 42.9 36.2 29.5 -
62 60.7 4.4 60.7 60.7 54.3 47.6 40.8 34.1 56.6 4.8 56.6 56.6 52.4 45.7 39.0 32.4
57 53.0 4.3 53.0 53.0 53.0 46.5 39.8 33.0 52.1 4.8 52.1 52.1 52.1 45.4 38.7 32.0
2000
72 75.6 4.8 51.9 44.6 37.4 30.1 - - 70.4 5.3 49.7 42.4 35.2 27.9 - -
67 68.8 4.6 61.7 54.5 47.2 40.0 32.7 - 63.7 5.1 59.4 52.1 44.8 37.6 30.3 -
62 61.9 4.5 61.9 61.9 57.0 49.8 42.5 35.3 57.5 5.0 57.5 57.5 54.8 47.5 40.2 32.9
57 54.1 4.5 54.1 54.1 54.1 46.8 39.6 32.4 52.9 4.9 52.9 52.9 52.9 45.6 38.3 31.1
95°F 105°F
1500
77 68.5 5.6 31.9 26.1 20.4 - - - 63.9 6.2 29.6 24.0 18.4 - - -
72 62.3 5.4 40.2 34.4 28.7 22.9 - - 57.6 6.0 37.8 32.2 26.5 20.9 - -
67 56.1 5.3 48.4 42.7 36.9 31.2 25.5 - 51.3 5.8 45.9 40.3 34.7 29.1 23.5 -
62 50.7 5.2 50.7 50.7 45.7 40.0 34.2 28.5 45.9 5.7 45.9 45.9 42.8 37.1 31.5 25.9
57 49.4 5.1 49.4 49.4 47.3 41.6 35.9 30.1 45.9 5.7 45.9 45.9 44.2 38.6 33.0 27.4
1550
77 69.4 5.6 32.7 26.9 21.0 - - - 64.7 6.1 30.5 24.7 18.9 - - -
72 63.1 5.4 41.2 35.4 29.5 23.7 - - 58.3 6.0 38.8 33.1 27.3 21.5 - -
67 56.8 5.2 49.7 43.9 38.0 32.2 26.3 - 51.9 5.8 47.2 41.5 35.7 29.9 24.2 -
62 51.4 5.1 51.4 51.4 47.1 41.2 35.4 29.5 46.5 5.7 46.5 46.5 44.0 38.2 32.5 26.7
57 50.0 5.1 50.0 50.0 48.8 42.9 37.1 31.2 46.4 5.7 46.4 46.4 45.5 39.7 34.0 28.2
1600
77 70.2 5.5 33.5 27.6 21.6 - - - 65.4 6.1 31.3 25.4 19.5 - - -
72 63.9 5.4 42.3 36.3 30.4 24.4 - - 59.0 5.9 39.9 34.0 28.1 22.2 - -
67 57.5 5.2 51.1 45.1 39.1 33.2 27.2 - 52.5 5.8 48.5 42.6 36.7 30.8 24.9 -
62 52.0 5.1 52.0 52.0 48.4 42.5 36.5 30.6 47.0 5.7 47.0 47.0 45.2 39.3 33.4 27.5
57 50.6 5.1 50.6 50.6 50.2 44.2 38.3 32.3 47.0 5.7 47.0 47.0 46.7 40.8 34.9 29.0
1800
72 64.5 5.5 44.9 38.3 31.7 25.0 - - 59.4 6.1 42.4 35.8 29.3 22.8 - -
67 58.1 5.4 54.1 47.4 40.8 34.2 27.6 - 52.9 6.0 50.5 44.8 38.3 31.8 25.3 -
62 52.5 5.3 52.5 52.5 50.5 43.9 37.2 30.6 47.4 5.8 47.4 47.4 46.3 39.8 33.3 26.8
57 51.1 5.2 51.1 51.1 50.9 44.3 37.7 31.0 47.3 5.8 47.3 47.3 47.2 40.7 34.2 27.7
2000
72 65.2 5.7 47.6 40.3 33.0 25.7 - - 59.9 6.3 44.8 37.7 30.6 23.4 - -
67 58.7 5.6 57.1 49.8 42.5 35.2 27.9 - 53.3 6.1 52.5 47.1 39.9 32.8 25.7 -
62 53.1 5.4 53.1 53.1 52.6 45.2 37.9 30.6 47.7 6.0 47.7 47.7 47.4 40.3 33.2 26.1
57 51.7 5.4 51.7 51.7 51.7 44.4 37.1 29.8 47.7 6.0 47.7 47.7 47.7 40.6 33.5 26.3
