294604-YTG-G-0511
Johnson Controls Unitary Products 23
DEQ024-060 Cooling Capacities
DEQ024 (2.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 27.3 1.5 10.8 8.5 6.2 - - - 25.8 1.7 11.7 9.4 7.1 - - -
72 26.2 1.5 16.0 13.7 11.4 9.1 - - 24.4 1.7 16.0 13.7 11.4 9.1 - -
67 25.2 1.5 21.2 18.9 16.6 14.4 12.1 - 22.9 1.7 20.3 18.0 15.7 13.4 11.1 -
62 23.5 1.5 23.5 21.6 17.9 15.6 13.3 11.0 21.2 1.6 21.2 20.2 17.9 15.6 13.3 11.0
57 22.6 1.5 22.6 22.6 19.7 17.4 15.1 12.8 20.7 1.6 20.7 20.7 18.9 16.6 14.3 11.9
700
77 28.6 1.5 12.1 9.7 7.2 - - - 27.1 1.7 13.1 10.4 7.8 - - -
72 27.5 1.5 18.1 15.5 13.0 10.5 - - 25.6 1.7 17.8 15.2 12.6 9.9 - -
67 26.3 1.5 24.1 21.4 18.9 16.4 13.9 - 24.0 1.7 22.6 19.9 17.3 14.7 12.0 -
62 24.6 1.5 24.6 23.7 20.4 17.9 15.4 12.9 22.2 1.6 22.2 21.7 19.7 17.1 14.5 11.8
57 23.6 1.5 23.6 23.6 22.4 19.8 17.3 14.8 21.8 1.6 21.8 21.8 20.8 18.2 15.5 12.9
800
77 29.8 1.5 13.3 10.8 8.1 - - - 28.3 1.7 14.5 11.5 8.5 - - -
72 28.7 1.5 20.1 17.4 14.6 11.9 - - 26.7 1.7 19.7 16.7 13.7 10.8 - -
67 27.5 1.5 26.9 23.9 21.2 18.4 15.7 - 25.1 1.7 24.8 21.9 18.9 15.9 13.0 -
62 25.8 1.5 25.8 25.8 22.9 20.2 17.4 14.7 23.2 1.6 23.2 23.2 21.6 18.6 15.6 12.7
57 24.7 1.5 24.7 24.7 24.7 22.3 19.6 16.8 22.8 1.6 22.8 22.8 22.8 19.8 16.8 13.9
900
72 30.4 1.5 19.1 15.8 12.5 9.2 - - 28.4 1.7 20.4 17.1 13.7 10.4 - -
67 29.1 1.5 27.0 21.7 18.4 15.1 11.8 - 26.7 1.7 25.6 22.2 18.9 15.6 12.2 -
62 27.3 1.5 27.3 27.3 20.6 17.3 14.0 10.7 24.7 1.6 24.7 24.7 21.6 18.2 14.9 11.6
57 26.1 1.5 26.1 26.1 23.0 19.7 16.4 13.2 24.1 1.6 24.1 24.1 22.8 19.4 16.1 12.7
95°F 105°F
600
77 24.3 1.9 12.6 10.3 7.9 - - - 22.1 2.0 12.7 9.5 7.2 - - -
72 22.5 1.8 16.0 13.7 11.3 9.0 - - 20.1 2.0 15.1 12.8 10.4 8.1 - -
67 20.7 1.8 19.4 17.1 14.7 12.4 10.1 - 18.1 1.9 17.5 16.0 13.7 11.4 9.0 -
62 18.8 1.8 18.8 18.8 17.9 15.6 13.2 10.9 16.7 1.9 16.7 16.7 16.0 13.7 11.3 9.0
57 18.9 1.8 18.9 18.9 18.1 15.8 13.4 11.1 17.1 1.9 17.1 17.1 16.3 13.9 11.6 9.3
700
77 25.6 1.9 14.1 11.2 8.4 - - - 23.2 2.0 14.6 10.6 7.7 - - -
72 23.7 1.8 17.6 14.8 12.1 9.3 - - 21.1 2.0 16.7 13.9 11.1 8.4 - -
67 21.7 1.8 21.1 18.5 15.7 12.9 10.2 - 19.0 1.9 18.7 17.2 14.6 11.8 9.1 -
62 19.8 1.8 19.8 19.8 19.1 16.3 13.5 10.8 17.6 1.9 17.6 17.6 17.1 14.3 11.5 8.8
57 19.9 1.8 19.9 19.9 19.3 16.5 13.8 11.0 17.9 1.9 17.9 17.9 17.3 14.6 11.8 9.0
800
77 26.8 1.9 15.6 12.1 9.0 - - - 24.3 2.0 16.6 11.6 8.1 - - -
72 24.8 1.8 19.2 16.0 12.8 9.6 - - 22.1 2.0 18.2 15.0 11.8 8.6 - -
67 22.8 1.8 22.8 19.8 16.6 13.5 10.3 - 19.9 1.9 19.9 18.4 15.5 12.3 9.1 -
62 20.7 1.8 20.7 20.7 20.2 17.0 13.8 10.7 18.4 1.9 18.4 18.4 18.1 14.9 11.7 8.5
57 20.8 1.8 20.8 20.8 20.5 17.3 14.1 10.9 18.8 1.9 18.8 18.8 18.4 15.2 12.0 8.8
900
72 26.4 1.8 21.7 18.3 14.9 11.5 - - 23.6 2.0 20.7 17.2 13.8 10.4 - -
67 24.2 1.8 24.2 22.8 19.4 16.0 12.6 - 21.2 2.0 21.2 20.5 18.1 14.7 11.2 -
62 22.0 1.8 22.0 22.0 22.6 19.2 15.8 12.4 19.6 1.9 19.6 19.6 19.9 16.4 13.0 9.6
57 22.1 1.8 22.1 22.1 22.5 19.1 15.7 12.3 20.0 1.9 20.0 20.0 20.4 16.9 13.5 10.1
