294604-YTG-G-0511
32 Johnson Controls Unitary Products
115°F 125°F
1400
77 48.6 4.5 26.7 19.6 14.2 - - - 46.1 5.0 27.0 18.5 13.1 - - -
72 44.7 4.5 33.1 27.7 22.3 16.9 - - 41.8 4.9 32.1 26.6 21.2 15.7 - -
67 40.8 4.4 39.5 35.8 30.4 25.1 19.7 - 37.5 4.8 37.5 34.7 29.3 23.8 18.4 -
62 37.7 4.4 37.7 37.7 35.3 29.9 24.5 19.1 34.4 4.9 34.4 34.4 32.5 27.1 21.6 16.2
57 38.7 4.4 38.7 38.2 35.4 30.0 24.6 19.2 35.8 4.9 35.8 35.2 32.3 26.9 21.4 16.0
1500
77 48.9 4.5 28.7 20.5 14.8 - - - 46.4 5.0 29.7 19.4 13.7 - - -
72 45.0 4.5 34.6 28.9 23.3 17.6 - - 42.1 4.9 33.6 27.9 22.2 16.4 - -
67 41.1 4.4 40.5 37.4 31.7 26.1 20.4 - 37.8 4.8 37.8 36.4 30.6 24.9 19.1 -
62 38.0 4.4 38.0 38.0 36.8 31.1 25.5 19.8 34.6 4.9 34.6 34.6 33.7 28.3 22.5 16.8
57 39.0 4.4 39.0 38.8 36.9 31.2 25.6 19.9 36.0 4.9 36.0 35.7 33.8 28.1 22.4 16.6
1600
77 49.3 4.5 30.7 21.3 15.4 - - - 46.7 5.0 32.4 20.3 14.3 - - -
72 45.3 4.5 36.1 30.1 24.2 18.3 - - 42.4 4.9 35.2 29.2 23.1 17.1 - -
67 41.4 4.4 41.4 38.9 33.0 27.1 21.2 - 38.0 4.8 38.0 38.0 32.0 25.9 19.9 -
62 38.3 4.4 38.3 38.3 38.3 32.3 26.4 20.5 34.8 4.9 34.8 34.8 34.8 29.5 23.4 17.4
57 39.3 4.4 39.3 39.3 38.4 32.4 26.5 20.6 36.3 4.9 36.3 36.3 35.3 29.3 23.3 17.2
1700
72 45.1 4.5 36.8 30.7 24.6 18.5 - - 42.0 5.0 35.8 29.6 23.4 17.2 - -
67 41.2 4.4 41.2 39.7 33.6 27.5 21.4 - 37.7 4.9 37.7 37.7 32.3 26.1 19.9 -
62 38.1 4.4 38.1 38.1 38.1 32.0 25.9 19.8 34.5 4.9 34.5 34.5 34.5 28.6 22.3 16.1
57 39.1 4.5 39.1 39.1 38.7 32.6 26.5 20.4 35.9 4.9 35.9 35.9 35.6 29.4 23.1 16.9
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
DEQ048 (4.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
