294604-YTG-G-0511
Johnson Controls Unitary Products 35
DEX024-048 Cooling Capacities
DEX024 (2.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 21.5 1.1 7.5 7.8 6.8 - - - 21.6 1.3 9.8 8.3 6.9 - - -
72 21.3 1.1 14.3 12.7 11.0 9.3 - - 20.7 1.3 14.8 12.8 10.8 8.9 - -
67 21.2 1.1 21.2 17.6 15.2 12.9 10.6 - 19.7 1.3 19.7 17.3 14.8 12.2 9.7 -
62 20.2 1.1 20.2 20.2 19.9 15.6 11.4 7.1 18.4 1.3 18.4 18.4 18.3 14.0 9.8 5.5
57 19.4 1.1 19.4 19.4 19.4 15.1 10.9 6.6 18.2 1.3 18.2 18.2 18.2 13.9 9.6 5.3
800
77 30.1 1.6 13.1 12.3 10.2 - - - 28.9 1.8 13.9 11.7 9.6 - - -
72 28.4 1.6 19.9 17.3 14.8 12.2 - - 26.9 1.8 19.4 16.8 14.1 11.4 - -
67 26.7 1.5 26.7 22.4 19.3 16.2 13.1 - 24.9 1.7 24.9 21.8 18.6 15.4 12.2 -
62 24.0 1.5 24.0 24.0 24.0 20.6 17.1 13.7 22.7 1.7 22.7 22.7 22.7 19.2 15.7 12.3
57 24.4 1.5 24.4 24.4 24.4 20.8 17.3 13.7 23.0 1.7 23.0 23.0 23.0 19.5 15.9 12.4
95°F 105°F
600
77 21.8 1.4 12.1 8.8 7.0 - - - 20.2 1.6 12.7 8.7 6.5 - - -
72 20.0 1.4 15.2 13.0 10.7 8.4 - - 18.4 1.6 14.7 12.4 10.1 7.8 - -
67 18.3 1.4 18.3 17.1 14.3 11.6 8.8 - 16.6 1.6 16.6 16.0 13.6 10.3 6.9 -
62 16.6 1.4 16.6 16.6 16.6 12.4 8.2 3.9 15.4 1.6 15.4 15.4 15.4 11.2 7.1 2.9
57 17.0 1.4 17.0 17.0 17.0 12.7 8.3 4.0 15.5 1.6 15.5 15.5 15.5 12.0 8.4 4.8
800
77 27.8 2.0 14.7 11.2 9.0 - - - 25.8 2.3 15.2 10.6 8.3 - - -
72 25.5 1.9 18.9 16.2 13.4 10.7 - - 23.6 2.2 18.3 15.5 12.7 9.9 - -
67 23.2 1.9 23.2 21.2 17.9 14.6 11.3 - 21.4 2.2 21.4 20.4 17.1 13.8 10.5 -
62 21.4 1.9 21.4 21.4 21.4 17.9 14.4 10.9 19.9 2.1 19.9 19.9 19.9 16.4 12.9 9.4
57 21.6 1.8 21.6 21.6 21.6 18.1 14.6 11.1 20.0 2.1 20.0 20.0 20.0 16.5 13.0 9.5
115°F
600
77 18.7 1.8 13.2 8.5 6.0 - - -
72 16.8 1.8 14.1 11.8 9.4 7.1 - -
67 15.0 1.8 15.0 15.0 12.9 9.0 5.1 -
62 14.2 1.8 14.2 14.2 14.2 10.1 6.0 1.9
57 14.1 1.8 14.1 14.1 14.1 11.3 8.4 5.6
800
77 23.7 2.5 15.7 10.1 7.6 - - -
72 21.7 2.4 17.6 14.8 11.9 9.1 - -
67 19.6 2.3 19.6 19.5 16.2 13.0 9.7 -
62 18.4 2.3 18.4 18.4 18.4 15.0 11.5 8.0
57 18.3 2.3 18.3 18.3 18.3 14.8 11.3 7.8
