DEX042 (3.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
925
77 40.2 1.9 21.0 17.4 13.7 - - - 37.3 2.2 19.2 15.7 12.2 - - -
72 37.1 1.9 26.3 22.4 18.5 14.7 - - 34.5 2.1 24.8 20.9 17.1 13.3 - -
67 34.0 1.9 31.6 27.5 23.3 19.2 15.1 - 31.6 2.1 30.3 26.2 22.1 18.0 13.8 -
62 30.5 1.9 30.5 30.5 27.7 23.2 18.8 14.3 28.1 2.1 28.1 28.1 26.5 22.0 17.6 13.2
57 29.4 1.8 29.4 29.4 29.4 24.8 20.1 15.5 27.5 2.1 27.5 27.5 27.5 22.9 18.3 13.7
1400
77 61.7 3.4 29.1 24.8 20.4 - - - 56.7 3.3 27.2 22.8 18.4 - - -
72 55.5 3.1 37.9 32.7 27.6 22.4 - - 51.6 3.3 36.1 31.0 25.8 20.7 - -
67 49.4 3.1 46.7 40.7 34.7 28.8 22.8 - 46.5 3.3 45.0 39.1 33.3 27.5 21.7 -
62 44.5 3.0 44.5 44.5 42.4 36.2 30.1 23.9 41.8 3.2 41.8 41.8 40.8 34.6 28.4 22.3
57 46.0 2.9 46.0 46.0 45.5 39.2 32.8 26.4 42.9 3.1 42.9 42.9 42.7 36.4 30.1 23.8
95°F 105°F
925
77 34.4 2.4 17.5 14.0 10.6 - - - 31.7 2.6 17.7 12.8 9.6 - - -
72 31.8 2.3 23.3 19.5 15.7 11.9 - - 29.0 2.6 21.9 18.3 14.6 10.9 - -
67 29.2 2.3 29.1 24.9 20.8 16.7 12.6 - 26.3 2.6 26.2 23.8 19.6 15.5 11.4 -
62 25.7 2.4 25.7 25.7 25.3 20.9 16.5 12.1 23.5 2.6 23.5 23.5 23.3 18.9 14.5 10.1
57 25.6 2.4 25.6 25.6 25.6 21.0 16.5 11.9 23.6 2.7 23.6 23.6 23.5 19.1 14.7 10.4
1400
77 51.7 3.8 25.3 20.8 16.3 - - - 47.4 4.1 24.9 18.7 14.5 - - -
72 47.6 3.7 34.3 29.2 24.1 19.0 - - 43.5 4.0 32.2 27.3 22.4 17.5 - -
67 43.5 3.5 43.3 37.6 31.9 26.2 20.5 - 39.5 3.9 39.4 35.9 30.3 24.7 19.1 -
62 39.2 3.5 39.2 39.2 39.2 33.0 26.8 20.7 36.2 3.8 36.2 36.2 36.2 30.1 24.0 17.9
57 39.8 3.5 39.8 39.8 39.8 33.6 27.4 21.2 36.7 3.8 36.7 36.7 36.8 30.7 24.6 18.5
115°F
925
77 28.9 2.9 17.9 11.5 8.6 - - -
72 26.2 2.9 20.6 17.1 13.5 9.9 - -
67 23.4 2.9 23.4 22.6 18.4 14.3 10.1 -
62 21.3 2.9 21.3 21.3 21.3 16.9 12.6 8.2
57 21.5 2.9 21.5 21.5 21.4 17.2 13.0 8.8
1400
77 43.2 4.5 24.6 16.5 12.6 - - -
72 39.4 4.4 30.1 25.4 20.7 16.0 - -
67 35.6 4.3 35.6 34.2 28.7 23.3 17.8 -
62 33.2 4.2 33.2 33.2 33.3 27.2 21.2 15.2
57 33.6 4.2 33.6 33.6 33.8 27.8 21.9 15.9
