DEY060 Cooling Capacities
DEY060 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1150
77 58.8 2.7 27.2 22.9 18.6 - - - 55.3 3.1 25.4 21.4 17.4 - - -
72 53.4 2.7 33.7 29.3 24.9 20.5 - - 50.3 3.1 32.6 28.2 23.9 19.5 - -
67 47.9 2.8 40.3 35.8 31.3 26.8 22.4 - 45.2 3.1 39.9 35.1 30.3 25.5 20.7 -
62 45.5 2.7 45.5 44.0 39.0 34.6 30.2 25.8 42.9 3.1 42.9 42.2 37.8 33.4 29.1 24.7
57 44.6 2.7 44.6 44.6 42.8 38.3 33.8 29.4 41.8 3.1 41.8 41.8 40.3 35.7 31.2 26.7
1750
77 73.6 4.5 30.7 26.7 22.7 - - - 72.7 4.9 31.8 27.0 22.1 - - -
72 69.7 4.2 44.0 38.8 33.5 28.2 - - 67.4 4.8 43.9 38.1 32.4 26.6 - -
67 65.8 4.0 57.4 50.9 44.3 37.8 31.3 - 62.1 4.6 55.9 49.3 42.6 36.0 29.4 -
62 61.0 4.0 61.0 61.0 54.7 47.2 39.6 32.0 57.1 4.5 57.1 57.1 52.2 44.9 37.6 30.3
57 58.9 3.9 58.9 58.9 58.2 50.7 43.3 35.8 56.4 4.5 56.4 56.4 55.6 48.0 40.4 32.8
95°F 105°F
1150
77 51.8 3.5 23.5 19.9 16.3 - - - 48.4 3.9 23.6 19.3 15.0 - - -
72 47.1 3.4 31.5 27.2 22.8 18.4 - - 44.4 3.9 30.6 26.1 21.7 17.3 - -
67 42.5 3.4 39.5 34.4 29.3 24.2 19.0 - 40.3 3.9 37.6 33.0 28.4 23.8 19.2 -
62 40.3 3.4 40.3 40.3 36.6 32.3 27.9 23.6 37.6 3.9 37.6 37.6 35.1 30.8 26.5 22.1
57 38.9 3.4 38.9 38.9 37.7 33.2 28.6 24.1 36.5 3.8 36.5 36.5 35.3 30.4 25.4 20.4
1750
77 71.9 5.1 33.0 27.3 21.6 - - - 66.9 5.8 31.6 25.4 19.8 - - -
72 65.2 5.1 43.7 37.5 31.3 25.1 - - 60.7 5.7 42.1 35.9 29.6 23.4 - -
67 58.5 5.1 54.5 47.7 41.0 34.2 27.5 - 54.6 5.7 52.6 46.3 39.5 32.7 25.9 -
62 53.3 4.8 53.3 53.3 49.6 42.7 35.7 28.7 49.7 5.5 49.7 49.7 47.9 40.7 33.5 26.3
57 54.0 4.8 54.0 54.0 53.0 45.2 37.5 29.8 50.9 5.5 50.9 50.9 49.9 42.2 34.5 26.8
115°F
1150
77 45.1 4.3 23.6 18.7 13.8 - - -
72 41.6 4.3 29.6 25.1 20.6 16.2 - -
67 38.1 4.3 35.6 31.6 27.5 23.4 19.4 -
62 34.8 4.3 34.8 34.8 33.7 29.3 25.0 20.7
57 34.1 4.3 34.1 34.1 33.0 27.5 22.1 16.7
1750
77 61.9 6.2 30.2 23.6 18.0 - - -
72 56.3 6.1 40.4 34.2 28.0 21.8 - -
67 50.7 6.0 50.7 44.8 38.0 31.1 24.3 -
62 46.2 5.8 46.2 46.2 46.2 38.8 31.3 23.9
57 47.9 5.8 47.9 47.9 46.7 39.1 31.5 23.9
