York AFFINITY DEZ024 - Typical Duct Applications

294604-YTG-G-0511
Johnson Controls Unitary Products 69
Unit Typical Duct Applications
Unit Typical Slab on Ground Installation
ROOF CURB
INSTALLATION
REAR DUCT
ROOF CURB
INSTALLATION
BOTTOM DUCT
SLAB ON GROUND
INSTALLATION
TO POWER SUPPLY
SUPPLY AIR
DUCT
RETURN AIR
DUCT
FIELD SUPPLIED
DISCONNECT SWITCH
LOCATED TO REAR OF UNIT
CONTROL WIRING
TO INDOOR
THERMOSTAT
