DEY060 Physical Data
Component
Models
DEY060
Nominal Tonnage 5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu) 60.4
ARI net capacity (Btu) 58.5
EER 11.6
SEER 14.5
Nominal CFM 1750
System power (KW) 5.0
Refrigerant type R-410A
Refrigerant charge (lb-oz) 10-8
DIMENSIONS (inches)
Length 49 1/8
Width 47 1/4
Height 41 1/2
OPERATING WT. (lbs.) 460
COMPRESSORS
Type Scroll 2-spd
Quantity 1
CONDENSER COIL DATA
Face area (Sq. Ft.) 16.4
Rows 2
Fins per inch 20
Tube diameter (in.) 3/8
Circuitry Type Interlaced
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 5.63
Rows 3
Fins per inch 16
Tube diameter 3/8
Circuitry Type Interlaced
Refrigerant control TX Valve
CONDENSER FAN DATA
Fan diameter (Inch) 22
Type Prop.
Drive type Direct
No. speeds 1
Number of motors 1
Motor HP each 1/3
RPM 1100
Nominal total CFM 3000
DIRECT DRIVE EVAP FAN DATA
Quantity 1
Fan Size (Inch) 11 x 10
Type Centrifugal
No. speeds 2
Motor HP each 1
RPM Variable
Frame size 48
FILTERS
Quantity - Size 2 - 22 x 14 x 1
