York CZH024 THRU 060 Technical Guide

350154-YTG-B-0408
Johnson Controls Unitary Products 11
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTE: KW RATING IS FOR OUTDOOR AND INDOOR UNITS.
LOW CFM
COOLING PERFORMANCE DATA - LOW CFM 1-STAGE OPERATION
OUTDOOR UNIT MODEL NO. CZH03611
INDOOR COIL MODEL NO. FC62D + MV12D
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 750 800 850
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 25.4 26.8 27.2 29.7 32.8 25.9 27.0 27.3 30.1 33.0 26.4 27.2 27.5 30.4 33.2
S.C. 25.0 22.9 19.4 19.3 15.3 25.6 23.7 19.9 19.8 15.7 26.1 24.6 20.4 20.2 16.1
K.W. 1.00 0.99 0.99 0.96 0.93 0.99 0.98 0.98 0.95 0.92 0.97 0.97 0.97 0.94 0.91
75
T.C. 24.3 25.5 25.7 28.3 31.2 24.9 25.7 25.9 28.6 31.3 25.4 26.0 26.1 28.9 31.5
S.C. 24.0 22.3 18.8 18.7 14.8 24.6 23.1 19.4 19.2 15.3 25.1 23.8 19.9 19.7 15.7
K.W. 1.24 1.23 1.23 1.20 1.17 1.22 1.22 1.22 1.19 1.16 1.21 1.21 1.21 1.18 1.16
85
T.C. 23.3 24.2 24.3 26.9 29.5 23.8 24.5 24.5 27.2 29.7 24.3 24.7 24.8 27.5 29.8
S.C. 23.0 21.8 18.3 18.2 14.4 23.6 22.4 18.8 18.7 14.9 24.1 23.0 19.3 19.2 15.3
K.W. 1.47 1.47 1.47 1.44 1.41 1.46 1.46 1.46 1.43 1.41 1.45 1.45 1.45 1.42 1.40
95
T.C. 22.2 22.9 22.8 25.4 27.9 22.7 23.2 23.1 25.8 28.0 23.3 23.5 23.4 26.1 28.2
S.C. 22.0 21.2 17.7 17.6 14.0 22.6 21.7 18.2 18.2 14.5 23.1 22.2 18.8 18.7 14.9
K.W. 1.71 1.71 1.71 1.68 1.65 1.70 1.70 1.70 1.67 1.65 1.69 1.69 1.69 1.66 1.64
105
T.C. 20.8 21.3 21.0 23.6 26.0 21.3 21.7 21.3 23.8 26.1 21.9 22.1 21.5 24.1 26.2
S.C. 20.6 20.0 16.8 16.8 13.4 21.2 20.5 17.4 17.4 13.7 21.7 21.0 17.9 17.9 14.1
K.W. 2.03 2.03 2.03 2.01 1.98 2.02 2.02 2.02 2.00 1.97 2.00 2.01 2.01 1.99 1.97
115
T.C. 19.4 19.7 19.3 21.7 24.1 20.0 20.2 19.5 22.0 24.2 20.5 20.7 19.7 22.2 24.3
S.C. 19.2 18.8 16.0 16.1 12.8 19.8 19.3 16.6 16.6 13.0 20.4 19.8 17.1 17.1 13.3
K.W. 2.34 2.33 2.34 2.32 2.30 2.33 2.33 2.33 2.31 2.29 2.31 2.32 2.32 2.30 2.28
125
T.C. 18.0 18.2 17.5 19.9 22.2 18.6 18.8 17.7 20.1 22.3 19.1 19.3 18.0 20.4 22.4
S.C. 17.8 17.6 15.2 15.3 12.2 18.4 18.1 15.8 15.8 12.3 19.0 18.5 16.4 16.3 12.5
K.W. 2.65 2.64 2.65 2.63 2.62 2.64 2.64 2.65 2.63 2.61 2.62 2.63 2.64 2.62 2.60
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
AV36C – 1.00 1.00 1.01
MV12B FC/MC/PC43B 1.00 0.99 1.03
MV12B FC/MC/PC43C 1.00 0.99 1.03
MV16C FC/MC/PC43C 1.00 1.00 1.03
MV12D FC/MC/PC48D 1.00 0.99 1.00
MV12D UC48D 1.00 0.99 1.00
MV16C FC/MC/PC48C 1.01 1.01 1.01
MV16C FC/MC/PC48D 1.01 1.01 1.01
MV16C UC48D 1.01 1.01 1.01
MV20D FC/MC/PC48D 1.00 1.00 1.01
MV20D UC48D 1.00 1.00 1.01
MV12D FC/MC62D 1.00 1.00 1.00
MV20D FC/MC62D 1.01 1.01 1.01
Variable Speed
Furnace
Coil
T.C. S.C. KW
PV8*A12 FC/MC/PC37A 0.99 0.99 1.03
PV9*A12 FC/MC/PC37A 1.00 0.99 1.04
PV8*B16 FC/MC/PC43B 0.99 0.99 1.02
PV8*B16 FC/MC/PC43C 0.99 0.99 1.02
PV8*C16 FC/MC/PC43C 0.96 0.96 1.00
PV8*C20 FC/MC/PC43C 1.00 1.00 1.02
P(C,V)9*B12 FC/MC/PC43B 1.00 0.99 1.03
P(C,V)9*B12 FC/MC/PC43C 1.00 0.99 1.03
P(C,V)9*C16 FC/MC/PC43C 1.00 1.00 1.01
P(C,V)9*C20 FC/MC/PC43C 1.00 1.00 1.03
PV8*C16 FC/MC/PC48C 0.96 0.96 0.98
PV8*C16 FC/MC/PC48D 0.96 0.96 0.98
PV8*C16 UC48D 0.96 0.96 0.98
PV8*C20 FC/MC/PC48C 1.01 1.01 1.00
PV8*C20 FC/MC/PC48D 1.01 1.01 1.00
PV8*C20 UC48D 1.01 1.01 1.00
P(C,V)9*C16 FC/MC/PC48C 1.01 1.01 0.99
P(C,V)9*C16 FC/MC/PC48D 1.01 1.01 0.99
P(C,V)9*C16 UC48D 1.01 1.01 0.99
P(C,V)9*C20 FC/MC/PC48C 1.01 1.01 1.02
P(C,V)9*C20 FC/MC/PC48D 1.01 1.01 1.02
P(C,V)9*C20 UC48D 1.01 1.01 1.02
P(C,V)9*D20 FC/MC/PC48D 1.01 1.01 1.01
P(C,V)9*D20 UC48D 1.01 1.01 1.01
PV8*C20 FC/MC62D 1.01 1.01 1.01
P(C,V)9*C20 FC/MC62D 1.01 1.01 1.02
P(C,V)9*D20 FC/MC62D 1.01 1.01 1.02
PV8*C16 HC42C 0.96 0.96 0.99
PV8*C20 HC42C 1.00 1.00 1.01
P(C,V)9*C16 HC42C 1.00 0.99 1.01
P(C,V)9*C20 HC42C 1.00 1.00 1.03
Variable Speed
Furnace
Coil
T.C. S.C. KW
