BI-FLOW
TXV/
CHECK
VALVE**
INDOOR COIL
COMPRESSOR
4-WAY
REVERSING
VALVE*
SUCTION
ACCUMULATOR
OUTDOOR
COIL
COOLING CYCLE FLOW
HEATING CYCLE FLOW
FIELD CONNECTED LINE
FIELD CONNECTED LINE
LIQUID
SENSOR
**NOTE: The indoor coil is shipped with an orifice.
The orifice must be replaced with a TXV kit.
CHECK VALVE
FILTER DRYER
(solid core)
.
* SHOWN IN COOLING POSITION
ORIFICE (heating)
FIGURE 13 -
FLOW DIAGRAM - 060
—(10 & 12 SEER Single Phase)
INDOOR COIL
COMPRESSOR
4-WAY
REVERSING
VALVE*
SUCTION
ACCUMULATOR
OUTDOOR
COIL
COOLING CYCLE FLOW
HEATING CYCLE FLOW
* SHOWN IN COOLING POSITION
FIELD CONNECTED LINE
FIELD
CONNECTED LINE
LIQUID
SENSOR
Non Adjustable Thermal
Expansion Valve (Heating)
FILTER DRYER
(solid core).
Non Adjustable Thermal
Expansion Valve (Cooling)
FIGURE 14 -
FLOW DIAGRAM - 024 thru 048
—(14 SEER)
515.16-N3Y
Unitary Products Group 11
