York E*RC Series User Manual

L1
L2
CONTACTOR
CRANKCASE
HEATER
SWITCH
DUAL RUN/FAN
CAPACITOR
GROUND
LUG
ADJUSTABLE HIGH VOLTAGE CONDUIT PLATE
DEFROST
CONTROL
BOARD
“FINGERED”
BUSHING
LOW VOLTAGE BOX
FAN
MOTOR
PLUG
FIGURE 4 -
OUTDOOR UNIT CONTROL BOX
—
SINGLE PHASE
— (10 & 12 SEER)
CONTACTOR
DUAL
RUN/FAN
CAPACITOR
GROUND
LUG
ADJUSTABLE HIGH VOLTAGE CONDUIT PLATE
DEFROST
CONTROL
BOARD
“FINGERED” BUSHING
LOW VOLTAGE BOX
FAN
MOTOR
PLUG
START
RELAY
START
CAPACITOR
FIGURE 5 -
OUTDOOR UNIT CONTROL BOX
—
SINGLE PHASE
— (14 SEER Model)
515.16-N3Y
6 Unitary Products Group

York E*RC Series Specifications

General

Brand	York
Model	E*RC Series
Category	Heat Pump
Language	English
