036-21300-002-A-0905
22 Unitary Products Group
TABLE 22: KEU ELECTRICAL DATA
Model
(TONS)
Power
Supply
Voltage
Indoor
Motor
FLA
Heater
Model
Number
Nominal
Heater
KW
Applied
Heater KW
Electric
Heat Amps
Min.
Circuit
Ampacity
(AMPS)
Max. Fuse
1
/
HACR
Breaker
2
(AMPS)
060
3
(5)
208 7.6
None -- -- -- 9.5 15
2HT04501025 10 7.5 20.8 35.6 40
2HT04501625 16 12.0 33.4 51.2 60
2HT04502625 26 19.5 54.2 77.3 80
240 6.9
None -- -- -- 8.6 15
2HT04501025 10 10.0 24.1 38.7 40
2HT04501625 16 16.0 38.5 56.7 60
2HT04502625 26 26.0 62.5 86.8 90
090
(7.5)
208 6.6
None -- -- -- 8.3 15
2HS04501025 10 7.5 20.8 34.3 35
2HS04501625 16 12.0 33.4 49.9 50
2HS04502625 26 19.5 54.2 76.0 80
2HS04503625 36 27.0 75.1 102.1 110
240 6.0
None -- -- -- 7.5 15
2HS04501025 10 10.0 24.1 37.6 40
2HS04501625 16 16.0 38.5 55.6 60
2HS04502625 26 26.0 62.5 85.7 90
2HS04503625 36 36.0 86.6 115.8 125
460 3.0
None -- -- -- 3.8 15
2HS04501046 10 10.0 12.0 18.8 20
2HS04501646 16 16.0 19.2 27.8 30
2HS04502646 26 26.0 31.3 42.8 45
2HS04503646 36 36.0 43.3 57.9 60
575 2.4
None -- -- -- 3.0 15
2HS04501058 10 10.0 9.6 15.0 20
2HS04501658 16 16.0 15.4 22.2 25
2HS04502658 26 26.0 25.0 34.3 35
2HS04503658 36 36.0 34.6 46.3 50
120
(10)
208 7.5
None -- -- -- 9.4 15
2HS04501025 10 7.5 20.8 35.4 40
2HS04501625 16 12.0 33.4 51.1 60
2HS04502625 26 19.5 54.2 77.1 80
2HS04503625 36 27.0 75.1 103.2 110
240 6.8
None -- -- -- 8.5 15
2HS04501025 10 10.0 24.1 38.6 40
2HS04501625 16 16.0 38.5 56.6 60
2HS04502625 26 26.0 62.5 86.7 90
2HS04503625 36 36.0 86.6 116.8 125
460 3.4
None -- -- -- 4.3 15
2HS04501046 10 10.0 12.0 19.3 20
2HS04501646 16 16.0 19.2 28.3 30
2HS04502646 26 26.0 31.3 43.3 45
2HS04503646 36 36.0 43.3 58.4 60
575 2.7
None -- -- -- 3.4 15
2HS04501058 10 10.0 9.6 15.4 20
2HS04501658 16 16.0 15.4 22.6 25
2HS04502658 26 26.0 25.0 34.6 35
2HS04503658 36 36.0 34.6 46.7 50
