York GY8S User Manual

036-21618-002 Rev. A (1004)
Unitary Products Group 3
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
* ESP (External Static Pressure) .5" WG is at furnace outlet ahead of cooling coil.
1. Airflows above 1800 CFM (50.97 m
3
/min) require either return from two sides or one side plus bottom.
2. Motor voltage at 115 V.
3. NR = Operation at this static pressure is not recommended.
RATINGS & PHYSICAL / ELECTRICAL DATA - UPFLOW MODELS
Input
MBH
Output
MBH
Nominal
CFM
Cabinet Width
In.
AFUE Air Temp. Rise °F
40 32 1200 14-1/2 80.0 25-55
60 48 1200 14-1/2 80.0 25-55
80 64 1200 14-1/2 80.0 35-65
80 64 1600 17 1/2 80.0 25-55
80 64 2200 21 80.0 25-55
100 80 1200 17 1/2 80.0 40-70
100 80 1600 17 1/2 80.0 35-65
100 80 2000 21 80.0 25-55
115 92 1600 21 80.0 35-65
115 92 2000 21 80.0 30-60
130 104 2000 24-1/2 80.0 35-65
Input
MBH
Max. Outlet
Air Temp °F
Blower
Blower
Size In.
Total Unit
Amps
Max Over-current
Size (awg) @ 75 ft.
protect
Min.
Wire
one way
Operation
WGT. LBS
40 155 1/2 7.1 10 x 8 9.0 20 14 105
60 155 1/2 7.1 10 x 8 9.0 20 14 110
80 170 1/2 7.1 10 x 8 9.0 20 14 117
80 155 3/4 11.5 11 x 8 12.0 20 14 126
80 165 1.0 14 11 x 11 14.0 20 12 140
100 170 1/2 7.1 10 x 8 12.0 20 14 128
100 165 3/4 11.5 11 x 8 12.0 20 14 134
100 155 1.0 14 11 x 11 14.0 20 12 145
115 170 3/4 11.5 10 x 10 12.0 20 14 145
115 170 1.0 14 11 x 11 14.0 20 12 147
130 165 1.0 14 11 x 11 14.0 20 12 158
FILTER SIZES
BTU/H
Input / Output
CFM
Cabinet
Size
Side
(in)
Bottom
(in)
40/32 1200 A 16 x 25 14 x 25
60/48 1200 A 16 x 25 14 x 25
80/64 1200 A 16 x 25 14 x 25
80/64 1600 B 16 x 25 16 x 25
80/64 2200 C (2) 16 x 25 20 x 25
100/80 1200 B 16 x 25 16 x 25
100/80 1600 B 16 x 25 16 x 25
100/80 2000 C (2) 16 x 25 20 x 25
115/92 1600 C 16 x 25 20 x 25
115/92 2000 C (2) 16 x 25 20 x 25
130/104 2000 D (2) 16 x 25 22 x 25
