York H1RD042S06 User Manual

036-21339-001 Rev. C (0602)
Unitary Products Group 3
- = Not applicable
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
TOTAL
CAPACITY
SENSIBLE
CAPACITY
SEER
W/O TXV
SEER
+ TXV
3
EER
1 PH 13 SEER AC WITH N-AH / G2FD
H1RD018S06 N1AHB08 2,5,8,10 17 G2FD024S17 600 20.8 14.6 - 13.75 12.45
H1RD024S06
N1AHB08 2,5,8,10 17 G2FD024S17 800 23.8 16.6 - 13.30 12.00
N1AHB08 5,8,10,15,19 17 G2FD030S17 800 24.2 17.0 - 13.60 12.20
H1RD030S06
N1AHB12 5,8,10,15,19 17 G2FD030S17 1000 29.2 20.4 - 13.25 11.65
N1AHB12 5,8,10,15,19 17 G2FD036S17 1000 29.4 20.4 - 13.25 11.65
H1RD036S06
N1AHB12 5,8,10,15,19 17 G2FD036S17 1200 33.6 24.2 - 13.00 11.60
N1AHB12 5,8,10,15,19 17 G2FD046S17 1200 34.8 24.9 - 13.00 11.80
H1RD042S06
N1AHC16 5,8,10,15,20 21 G2FD042S21 1400 40.5 27.8 - 13.30 11.60
N1AHC16 5,8,10,15,20 21 G2FD048S21 1400 41.0 28.5 - 13.50 11.80
H1RD048S06
N1AHC16 5,8,10,15,20 21 G2FD048S21 1600 45.5 31.3 - 13.25 11.90
N1AHD20 8,10,15,20,25,30 24 G2FD060S24 1600 46.5 31.7 - 13.50 12.10
N1AHD20 8,10,15,20,25,30 24 G2FD061H24 1600 47.0 32.2 - 13.70 12.20
H1RD060S06
N1AHD20 8,10,15,20,25,30 24 G2FD060S24 1900 53.5 37.1 - 13.25 12.00
N1AHD20 8,10,15,20,25,30 24 G2FD061H24 2050 54.5 39.1 - 13.25 12.10
1 PH 13 SEER AC / N1VS - VARIABLE SPEED
H1RD018S06 N1VSB12 5,8,10,15,19 17 G2FD024S17 600 21.4 15.5 - 15.50 13.90
H1RD024S06
N1VSB12 5,8,10,15,19 17 G2FD024S17 825 24.4 17.4 - 15.00 13.35
N1VSB12 5,8,10,15,19 17 G2FD036S17 825 25.4 18.2 - 15.75 14.05
H1RD030S06
N1VSB12 5,8,10,15,19 17 G2FD036S17 1000 30.4 21.7 - 14.25 13.05
N1VSB12 5,8,10,15,19 17 G2FD046S17 1000 31.0 22.1 - 15.50 13.40
H1RD036S06
N1VSB12 5,8,10,15,19 17 G2FD036S17 1200 34.0 24.6 - 13.75 12.35
N1VSB12 5,8,10,15,19 17 G2FD046S17 1200 35.4 25.5 - 14.00 12.70
N1VSC16 5,8,10,15,20 21 G2FD048S21 1200 36.4 26.0 - 14.50 13.25
H1RD042S06 N1VSC16 5,8,10,15,20 21 G2FD048S21 1380 42.0 28.9 - 14.50 12.70
H1RD048S06
N1VSC16 5,8,10,15,20 21 G2FD048S21 1600 46.5 31.9 - 13.75 12.60
N1VSD20 8,10,15,20,25,30 24 G2FD060S24 1600 47.0 32.2 - 14.00 12.70
N1VSD20 8,10,15,20,25,30 24 G2FD061H24 1600 47.5 32.7 - 14.00 12.90
H1RD060S06
N1VSD20 8,10,15,20,25,30 24 G2FD060S24 1780 53.5 36.3 - 13.50 12.35
N1VSD20 8,10,15,20,25,30 24 G2FD061H24 1780 54.5 37.0 - 13.75 12.60
1 PH 13 SEER AC / F2RP / RC / FP / FC / FV
4,5
H1RD018S06
F2RP/F2FP018 5,8,10 18 -- 600 19.8 14.6 - 13.20 12.05
F2RP/F2FP024 5,8,10 18 -- 600 21.0 15.0 - 14.00 12.60
F2RC/F2FC024 5,8,10 18 600 20.8 14.6 - 13.80 12.50
H1RD024S06
F2RC/F2FC024 5,8,10 18 -- 800 23.8 16.6 - 13.25 11.90
F2RC/F2FC030 5,8,10,15 18 -- 800 23.8 16.6 - 13.30 11.90
F2RP/F2FP024 5,8,10 18 -- 800 23.8 16.6 - 13.30 11.95
F2RP/F2FP030 5,8,10,15 18 -- 800 24.2 17.0 - 13.60 12.20
H1RD030S06
F2RC/F2FC030 5,8,10,15 18 -- 1000 29.6 20.4 - 13.25 11.65
F2RC/F2FC036 5,8,10,15, 19 21 -- 1000 29.8 21.3 - 14.00 12.05
F2RP/F2FP030 5,8,10,15 18 -- 1000 29.6 20.5 - 13.25 11.75
F2RP/F2FP036 5,8,10,15, 19 21 -- 1000 30.0 21.2 - 13.50 11.90
H1RD036S06
F2RP/F2FP036 5,8,10,15, 19 21 -- 1200 34.2 24.5 - 13.00 11.75
F2RP/F2FP042 5,8,10,15 24 -- 1200 34.4 24.5 - 12.80 11.55
F2RP045 5,8,10,15 24 -- 1200 35.8 26.1 - 13.50 12.25
F2RP048 5,8,10,15 24 -- 1200 35.6 25.5 - 13.00 11.70
H1RD042S06
F2FP/F2FP042 5,8,10,15 21 -- 1400 40.0 27.7 - 13.00 11.40
F2FP045 5,8,10,15 24 -- 1400 42.0 29.0 - 13.80 12.10
F2FP048 10,15,20,25 24 -- 1400 41.0 28.3 - 13.00 11.50
H1RD048S06
F2FP045 10,15,20,25 24 -- 1565 46.5 31.4 - 13.50 12.15
F2FP048 10,15,20,25 24 -- 1565 45.5 30.8 - 13.00 11.70
F2FP060 10,15,20,25 24 -- 1600 46.0 31.2 - 12.75 11.50
F2FV060 10,15,20,25 24 -- 1600 47.0 32.1 - 14.00 12.65
H1RD060S06
F2FP060 10,15,20,25 24 -- 1900 53.0 36.7 - 13.00 11.60
F2FV060 10,15,20,25 24 -- 1900 53.5 36.3 - 13.50 12.35
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1 G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2 Single phase units require single phase 2HK heaters.
3 TXV = Use 1TV700 series kit.
4 To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC
. models. All ratings remain the same.
5 FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D. standard.
