York H1RD042S06 User Manual

036-21339-001 Rev. C (0602)
Unitary Products Group 5
*Requires 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
H1RD036S06
1050
1350
14 G1FA036S14 1200 33.2 23.8 - 13.00 11.50
17,21 G1FA036S17,21 1200 32.8 23.4 - 12.80 11.40
17 G1FA048S17 1200 34.8 24.9 - 13.00 11.80
21,24 G1FA048S21,24 1200 35.4 25.3 - 13.00 11.95
14 G2FD035S14 1200 32.8 23.4 - 12.80 11.40
17 G2FD036S17 1200 33.6 24.2 - 13.00 11.60
21 G2FD036S21 1200 34.2 24.5 - 13.00 11.65
21 G2FD042S21 1200 34.6 24.6 - 13.00 11.75
17 G2FD046S17 1200 34.8 24.9 - 13.00 11.80
21,24 G2FD048S21,24 1200 35.6 25.8 - 13.25 12.05
- G1HD036 1200 33.8 24.2 - 13.00 11.65
- G1HD048 1200 35.4 25.3 - 13.25 11.95
17 G1NA036S17L 1200 35.0 24.5 - 13.00 11.85
21 G1NA048S21D 1200 35.0 24.5 - 13.00 11.85
24 G1NA042S24W 1200 35.6 25.9 - 13.25 12.10
14 G1UA036S14 1200 33.2 23.8 - 13.00 11.50
17,21 G1UA036S17,21 1200 32.8 23.4 - 12.80 11.40
17 G1UA048S17 1200 34.8 24.9 - 13.00 11.80
21,24 G1UA048S21,24 1200 35.4 25.3 - 13.00 11.95
H1RD042S06
1225
1575
17 G1FA048S17 1400 40.0 27.7 - 13.25 11.55
21,24 G1FA048S21,24 1400 40.5 28.0 - 13.30 11.65
21,24 G1FA060S21,24 1400 41.0 28.9 - 13.70 11.95
21 G2FD042S21 1400 40.5 27.8 - 13.30 11.60
17 G2FD046S17 1400 40.0 27.7 - 13.25 11.55
21,24 G2FD048S21,24 1400 41.0 28.5 - 13.50 11.80
- G1HD048 1400 40.5 28.0 - 13.30 11.65
21 G1NA048S21D 1400 40.0 27.0 - 13.25 11.55
24 G1NA042S24W 1400 41.0 28.5 - 13.50 11.80
17 G1UA048S17 1400 40.0 27.7 - 13.25 11.55
21,24 G1UA048S21,24 1400 40.5 28.0 - 13.30 11.65
21,24 G1UA060S21,24 1400 41.0 28.9 - 13.70 11.95
H1RD048S06
1400
1800
17 G1FA048S17 1600 44.5 30.1 - 13.00 11.60
21,24 G1FA048S21,24 1600 45.0 30.6 - 13.00 11.75
21,24 G1FA060S21,24 1600 46.5 31.7 - 13.50 12.10
17 G2FD046S17 1600 44.5 30.1 - 13.00 11.60
21,24 G2FD048S21,24 1600 45.5 31.3 - 13.25 11.90
24 G2FD060S24 1600 46.5 31.7 - 13.50 12.10
24 G2FD061H24 1600 47.0 32.2 - 13.70 12.20
- G1HD048 1600 45.0 30.6 - 13.00 11.70
- G1HD060 1600 45.5 30.8 - 13.00 11.85
24 G1NA042S24W 1600 46.0 31.4 - 13.25 11.90
21 G1NA048S21D 1600 44.0 29.5 - 13.00 11.60
17 G1UA048S17 1600 44.5 30.1 - 13.00 11.60
21,24 G1UA048S21,24 1600 45.0 30.6 - 13.00 11.75
21,24 G1UA060S21,24 1600 46.5 31.7 - 13.40 12.10
H1RD060S06
1650
2150
21,24 G1FA060S21,24 1900 53.5 37.1 - 13.25 12.00
24 G2FD060S24 1900 53.5 37.1 - 13.25 12.00
24 G2FD061H24 2050 54.5 39.1 - 13.25 12.10
- G1HD060 1900 52.5 36.0 - 13.00 11.75
24 G1NA060S24T 1900 53.0 35.9 - 13.00 11.90
21,24 G1UA060S21,24 1900 53.5 37.1 - 13.25 12.00
1 TXV = Use 1TV700 Series Kit.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Continued)
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
W
RATED
CFM
TOTAL
CAPACITY
SENSIBLE
CAPACITY
SEER + TXV
W/O TDR
SEER +
TXV
1
+ TDR*
EER
