York H1RD042S06 User Manual

036-21339-001 Rev. C (0602)
Unitary Products Group 7
1. For condensing unit only. Does not include effect of evaporator motor power or heat.
2. Performance based on 15° superheat and 15° sub-cooling at condensing unit.
a. Increase capacity 1% for each 2° increase in sub-cooling.
b. Decrease capacity 1% for each 2° decrease in sub-cooling.
3. Sub-cooling in excess of 20° may result in excessively high condensing temperature with air on condenser above 115°. Maximum recommended con-
densing temperature is 140°F.
H1RD048S06
P1XDD20V G2FD060S24 24 1600 46.5 31.6 - 13.5 12.2
P1DUB16V G1FA048S17 17 1460 44.5 29.3 - 13.3 12.0
P1DUB16V G1UA048S17 17 1460 44.5 29.3 - 13.3 12.0
P1DUC20V G1FA048S21 21 1500 45.0 30.1 - 13.5 12.2
P1DUC20V G1UA048S21 21 1500 45.0 30.1 - 13.5 12.2
P1DUC20V G2FD048S21 21 1500 45.5 30.7 - 13.7 12.4
P1XUC16V G1FA048S21 21 1420 45.0 29.5 - 13.7 12.4
P1XUC16V G1UA048S21 21 1420 45.0 29.5 - 13.7 12.4
P1XUC16V G2FD048S21 21 1420 45.5 30.1 - 14.0 12.5
P1XUC20V G1FA048S21 21 1450 45.0 29.6 - 13.5 12.2
P1XUC20V G1UA048S21 21 1450 45.0 29.6 - 13.5 12.2
P1XUC20V G2FD048S21 21 1450 45.5 30.2 - 13.7 12.3
P1XUD20V G1FA060S24 24 1470 46.5 30.9 - 14.0 12.6
P1XUD20V G1UA060S24 24 1470 46.5 30.9 - 14.0 12.6
P1XUD20V G2FD048S24 24 1430 45.5 30.1 - 13.7 12.4
P1XUD20V G2FD060S24 24 1470 46.5 30.9 - 14.0 12.6
H1RD060S06
P1XDD20V G2FD060S24 24 1580 52.5 34.3 - 13.3 12.2
P1DUC20V G1FA060S21 21 1630 53.0 34.9 - 13.4 12.4
P1DUC20V G1UA060S21 21 1630 53.0 34.9 - 13.4 12.4
P1XUC20V G1FA060S21 21 1590 53.0 34.5 - 13.3 12.4
P1XUC20V G1UA060S21 21 1590 53.0 34.5 - 13.3 12.4
P1XUD20V G1FA060S24 24 1560 53.0 34.4 - 13.5 12.5
P1XUD20V G1UA060S24 24 1560 53.0 34.4 - 13.5 12.5
P1XUD20V G2FD060S24 24 1560 53.0 34.4 - 13.5 12.5
P1XUD20V G2FD061H24 24 1560 53.5 34.9 - 13.8 12.8
1 G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2
TXV = Use 1TV700 Series Kit.
3 Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL
VARIABLE SPEED
FURNACE MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
TOTAL
CAPACITY
SENSIBLE
CAPACITY
SEER
W/O TXV
SEER
+ TXV
2
EER
COOLING PERFORMANCE
MODEL
SUCT. T/P
@ COMPR.
AIR TEMP ON CONDENSER
MODEL
SUCT. T/P
@ COMPR.
AIR TEMP ON CONDENSER
75°F95°F115°F75°F95°F115°F
TEMP. PSIG MBH KW MBH KW MBH KW TEMP. PSIG MBH KW MBH KW MBH KW
H1RD018S06
35 61.5 18.26 1.50 14.76 1.21 12.36 1.01
H1RD042S06
35 61.5 35.07 3.01 31.15 2.67 27.19 2.33
40 68.5 19.94 1.63 16.79 1.38 14.38 1.18 40 68.5 38.34 3.29 34.26 2.94 30.06 2.58
45 76.0 21.76 1.78 18.81 1.54 15.98 1.31 45 76.0 41.46 3.56 37.25 3.20 32.89 2.82
50 84.0 23.36 1.92 20.83 1.71 17.86 1.46 50 84.0 44.52 3.82 40.40 3.47 35.68 3.06
H1RD024S06
35 61.5 20.99 1.75 16.96 1.41 14.19 1.18
H1RD048S06
35 61.5 40.19 3.32 35.71 2.95 31.16 2.58
40 68.5 22.92 1.91 19.29 1.61 16.51 1.38 40 68.5 43.95 3.63 39.27 3.25 34.46 2.85
45 76.0 25.01 2.08 21.61 1.80 18.35 1.53 45 76.0 47.51 3.93 42.70 3.53 37.69 3.12
50 84.0 26.86 2.24 23.93 1.99 20.53 1.71 50 84.0 51.03 4.22 46.31 3.83 40.89 3.38
H1RD030S06
35 61.5 26.12 2.28 21.13 1.85 17.66 1.54
H1RD060S06
35 61.5 46.76 3.90 41.53 3.46 36.26 3.02
40 68.5 28.54 2.49 24.01 2.10 20.55 1.80 40 68.5 51.12 4.26 45.68 3.81 40.08 3.34
45 76.0 31.13 2.72 26.70 2.33 22.85 2.00 45 76.0 55.28 4.61 49.66 4.14 43.85 3.65
50 84.0 33.43 2.92 29.79 2.60 25.56 2.23 50 84.0 59.37 4.95 53.87 4.49 47.57 3.96
H1RD036S06
35 61.5 30.59 2.56 24.73 2.07 20.69 1.73
40 68.5 33.41 2.80 28.11 2.35 24.07 2.01
45 76.0 36.45 3.05 31.50 2.64 26.76 2.24
50 84.0 39.14 3.28 34.88 2.92 29.92 2.50
