York HB 180 - Unit Dimensions Lb180 and Lb240

036-21323-002-C-0206
22 Unitary Products Group
FIGURE 12 - UNIT DIMENSIONS LB180 AND LB240
4-5/8
4-5/8
12-1/4
3-1/2
5-1/4
3-3/8
1-3/4
Knockout
for Liquid
Piping
1-3/4
Hole
for Suction
Piping
4.0
LB 180
Piping
Connection
Dimensions
AIR
OUT
AIR
OUT
AIR
IN
AIR
IN
5/8 BOTTOM
PANEL
7/8 KNOCKOUTS FOR POWER
AND CONTROL WIRING
M
C
A
B
EVAPORATOR
COIL SECTION
D
D
D
E
LESS
BOTTOM
PANEL
{
BLOWER
SECTION
J
L
K
K
KNOCKOUT
FOR
SUCTION
PIPING
KNOCKOUT
FOR
LIQUID
PIPING
KNOCKOUT
FOR
DRAIN
PIPING
4-9/16
10-3/16
2-7/32
19-3/32
3-1/2
5-25/64
3-3/8
5
1-3/8
Knockout
for Liquid
Piping
1-3/4
Hole
for Suction
Piping
LB 240
Piping
Connection
Dimensions
F
G
H
5/8
5/8
5/8 Panel
TABLE 27: UNIT DIMENSIONS LB180 AND LB240
MODEL A B C D E F G H J K L M
LB180 89-1/2 85.0 26.0 29-1/2 59 1-7/16 15-7/8 12-7/16 15-13/16 16 16 20-3/4
LB240 100-1/8 95-5/8 33-1/4 36-5/8 73-1/4 2-1/2 18-7/8 16-1/2 15-13/16 21-7/8 18 22-9/16
