York LEU360 - Unit Dimensions - Leu360 & 480

550.13-TG2Y (1001)
Unitary Products Group 9
FIGURE 3 : UNIT DIMENSIONS - LEU360 & 480
TABLE 10: UNIT DIMENSIONS - LEU 360 & 480
MODEL A B C D E F G H J K M N P
LEU360
100-1/8 95-5/8 33-1/4 36-5/8 73-1/4 2-1/2 18-7/8 16-1/2 15-13/16 21-7/8 22-9/16 1 2-1/8
LEU480
103-1/8 98-5/8 40-5/8 44 88 2-1/2 18-7/8 23-7/8 20-11/16 21-7/8 20-11/16 1-1/8 1-5/8
