PHYSICAL & ELECTRICAL DATA
Model MV12B MV12D MV16C MV20D
Blower - Diameter x Width 10 x 7 10 x 10 10 x 10 10 x 10
Motor
HP 1/2 1/2 3/4 1
Nominal RPM 1200 1200 1200 1200
Voltage 208/230
Amps Full Load (230) 4.3 4.3 5.0 7.0
Filter
Type DISPOSABLE OR PERMANENT
Size
16 x 20 x 1 22 x 20 x 1 20 x 20 x 1 22 x 20 x 1
Permanent Type Kit
1PF0601BK 1PF0603BK 1PF0602BK 1PF0603BK
Filter Rack 1FR0717 1FR0724 1FR0721 1FR0724
Shipping / Operating Weight (lbs.) 68 / 62 88 / 82 75 / 69 93 / 87
COILS
Model Application
Refrig.
Conn.
Types
Face
Area
(Sq. Ft.)
Rows
Deep
Fin
Per
In.
Coil Size
Tube
Geometry
Tube
Dia.
Fin
Type
TXV
Operating
Weight
(Lbs.)
MC18A3XH1
Cooling /
Heat Pump
Sweat
3.40 2 14 (2) 14 x 17.5
1 x 0.866 3/8 Enhanced
None
53
MC18A2AH1 2A
MC18B3XH1
3.40 2 14 (2) 14 x 17.5
None
53
MC18B2AH1 2A
MC24A3XH1
4.38 2 14 (2) 18 x 17.5
None
56
MC24A2AH1 2A
MC24B3XH1
4.38 2 14 (2) 18 x 17.5
None
56
MC24B2AH1 2A
MC30A3XH1
4.38 2 14 (2) 18 x 17.5
None
56
MC30A2AH1 2A
MC30B3XH1
4.38 2 14 (2) 18 x 17.5
None
56
MC30B2AH1 2A
MC35B3XH1
3.90 3 12 (2) 16 x 17.5
None
65
MC35C3XH1 None
MC36A3XH1
4.86 2 14 (2) 20 x 17.5
None
64
MC36A2AH1 2A
MC36B3XH1
4.86 2 14 (2) 20 x 17.5
None
65
MC36B2AH1 2A
MC36C3XH1
4.86 2 14 (2) 20 x 17.5
None
65
MC36C2AH1 2A
MC42B3XH1
5.83 2 14 (2) 24 x 17.5
None
72
MC42B2CH1 2C
MC42C3XH1
5.83 2 14 (2) 24 x 17.5
None
72
MC42C2CH1 2C
MC48C3XH1
5.35 3 12 (2) 22 x 17.5
None
82
MC48C2CH1 2C
MC48D3XH1
5.35 3 12 (2) 22 x 17.5
None
82
MC48D2CH1 2C
MC60D3XH1
5.83 3 12 (2) 24 x 17.5
None
86
MC60D2CH1 2C
MC61D3XH1
6.80 3 12 (2) 28 x 17.5
None
98
MC61D2CH1 2C
