COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(Min.-max.)
W
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
YCJF24S41S1
600 - 1000 14,17 FC/MC/PC24 800 24.8 17.3 14.00 12.00
600 - 1000 14,17 FC/MC/PC30 800 24.8 17.3 14.00 12.00
600 - 1000 14 FC/MC/PC32 800 25 17.6 14.50 12.35
600 - 1000 17,21 FC/MC/PC35 800 25 17.6 14.50 12.35
600 - 1000 14,17,21 FC/MC/PC36 800 25 17.6 14.00 12.00
600 - 1000 14 FC/MC/PC37 800 25.4 17.9 14.50 12.35
600 - 1000 17,21 FC/MC/PC43 800 25.2 18 14.70 12.50
600 - 1000 21 FC/MC/PC48 800 25.6 18.3 14.80 12.65
600 - 1000 14 HC18 800 24.2 16.7 14.00 12.00
600 - 1000 14 HC30 800 24.8 17.4 14.00 12.00
600 - 1000 17 HC36 800 25 17.6 14.00 12.00
600 - 1000 21 HC42 800 25.4 18 14.50 12.35
600 - 1000 14,17 HD24 800 25.4 17.7 14.50 12.35
600 - 1000 14,17,21 HD36 800 24.8 17 14.00 12.00
600 - 1000 21 HD48 800 25.6 17.9 14.50 12.35
600 - 1000 14,17 UC24 800 25 17.5 14.00 12.00
600 - 1000 14,17 UC30 800 25 17.5 14.00 12.00
YCJF30S41S1
800 - 1200 14,17 FC/MC/PC30 1000 28.8 20.6 14.00 12.00
800 - 1200 14,17 FC/MC/PC32 1000 29 21 14.00 12.00
800 - 1200 17,21 FC/MC/PC35 1000 29 21 14.00 12.00
800 - 1200 14,17,21 FC/MC/PC36 1000 29 21 14.00 12.00
800 - 1200 14 FC/MC/PC37 1000 29.6 21.6 14.50 12.35
800 - 1200 17,21 FC/MC/PC43 1000 29.6 21.6 14.50 12.35
800 - 1200 21,24 FC/MC/PC48 1000 30 21.8 14.50 12.35
800 - 1200 17 HC36 1000 29 21 14.00 12.00
800 - 1200 21 HC42 1000 29.6 21.6 14.25 12.10
800 - 1200 14,17,21 HD36 1000 28.8 20.2 14.00 12.00
800 - 1200 21,24 HD48 1000 29.8 21.4 14.50 12.35
800 - 1200 14,17 UC30 1000 29 20.8 14.00 12.00
YCJF36S41S1
1000 - 1400 17,21 FC/MC/PC35 1200 33.6 24.6 14.00 11.90
1000 - 1400 14,17,21 FC/MC/PC36 1200 33.4 24.2 14.00 11.85
1000 - 1400 14 FC/MC/PC37 1200 34.4 25.2 14.50 12.20
1000 - 1400 17,21 FC/MC/PC43 1200 34.4 25.2 14.50 12.20
1000 - 1400 21,24 FC/MC/PC48 1200 34.6 25.4 14.50 12.25
1000 - 1400 17 HC36 1200 33.6 24.6 14.00 11.90
1000 - 1400 21 HC42 1200 34.4 25.2 14.50 12.20
1000 - 1400 14,17,21,24 HD48 1200 34.6 25 14.50 12.20
1000 - 1400 21,24 UC60 1200 33.2 23.8 14.00 11.75
YCJF42S41S1
1200 - 1600 17,21 FC/MC/PC43 1400.00 40.50 30.40 14.00 12.00
1200 - 1600 21,24 FC/MC/PC48 1400.00 41.00 30.80 14.50 12.30
1200 - 1600 21,24 FC/MC/PC60 1400.00 41.00 30.80 14.50 12.30
1200 - 1600 21 HC42 1400.00 40.50 30.40 14.00 12.00
1200 - 1600 14,17,21,24 HD48 1400.00 41.00 30.40 14.25 12.10
1200 - 1600 21,24 HD60 1400.00 41.50 31.20 14.50 12.30
1200 - 1600 21,24 FC/MC62 1400.00 41.00 31.00 14.50 12.30
YCJF48S41S1
1400 - 1800 21,24 FC/MC/PC48 1600.00 46.50 32.80 14.25 12.10
1400 - 1800 21,24 FC/MC/PC60 1600.00 46.50 32.60 14.50 12.35
1400 - 1800 14,17,21,24 HD48 1600.00 46.50 32.60 14.50 12.35
1400 - 1800 14,17,21,24 HD60 1600.00 47.50 33.20 14.50 12.35
1400 - 1800 21,24 FC/MC62 1600.00 47.00 32.80 14.50 12.35
YCJF60S41S1
1600 - 2000 21,24 FC/MC/PC60 1800.00 54.50 38.50 13.80 11.90
1600 - 2000 24 HC60 1800.00 54.50 38.50 13.50 11.65
1600 - 2000 21,24 FC/MC62 1800.00 57.00 39.00 14.00 12.10
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
