York YLAA User Manual

JOHNSON CONTROLS
FORM 150.72-EG6 (516)
46
YLAA VOLT HZ MCA
MIN
N/F
DISC
SW
MIN
DUAL
ELEM
FUSE
& CB
MAX
DUAL
ELEM
CB
SYSTEM # 1
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA
101
208 60 458 600 500 500 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 456 600 500 500 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 264 400 300 300 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 224 400 250 250 26.9 180 26.9 180 26.9 180 2 4 19
575 60 178 250 200 200 21.5 132 21.5 132 21.5 132 2 2.9 15.3
120
208 60 497 800 600 600 106.2 523 106.2 523 3 7.6 44
230 60 496 800 600 600 106.2 578 106.2 578 3 7.4 37
380 60 300 400 350 350 64.3 355 64.3 355 3 4.5 23.1
460 60 250 400 300 300 53.1 290 53.1 290 3 4 19
575 60 198 250 225 225 42.5 255 42.5 255 3 2.9 15.3
125
208 60 512 800 600 600 106.2 523 106.2 523 4 7.6 44
230 60 511 800 600 600 106.2 578 106.2 578 4 7.4 37
380 60 309 400 350 350 64.3 355 64.3 355 4 4.5 23.1
460 60 258 400 300 300 53.1 290 53.1 290 4 4 19
575 60 204 250 225 225 42.5 255 42.5 255 4 2.9 15.3
136
208 60 579 800 600 600 106.2 523 106.2 523 106.2 523 4 7.6 44
230 60 577 800 600 600 106.2 578 106.2 578 106.2 578 4 7.4 37
380 60 338 600 400 400 64.3 355 64.3 355 64.3 355 4 4.5 23.1
460 60 285 400 300 300 53.1 290 53.1 290 53.1 290 4 4 19
575 60 226 400 250 250 42.5 255 42.5 255 42.5 255 4 2.9 15.3
142
208 60 579 800 600 600 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 577 800 600 600 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 338 600 400 400 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 285 400 300 300 53.1 290 53.1 290 53.1 290 5 4 19
575 60 226 400 250 250 42.5 255 42.5 255 42.5 255 5 2.9 15.3
155
208 60 618 800 700 700 106.2 523 106.2 523 106.2 523 4 7.6 44
230 60 617 800 700 700 106.2 578 106.2 578 106.2 578 4 7.4 37
380 60 374 600 400 400 64.3 355 64.3 355 64.3 355 4 4.5 23.1
460 60 311 400 350 350 53.1 290 53.1 290 53.1 290 4 4 19
575 60 246 400 300 300 42.5 255 42.5 255 42.5 255 4 2.9 15.3
156
208 60 634 800 700 700 106.2 523 106.2 523 106.2 523 6 7.6 44
230 60 632 800 700 700 106.2 578 106.2 578 106.2 578 6 7.4 37
380 60 383 600 400 400 64.3 355 64.3 355 64.3 355 6 4.5 23.1
460 60 319 400 350 350 53.1 290 53.1 290 53.1 290 6 4 19
575 60 252 400 300 300 42.5 255 42.5 255 42.5 255 6 2.9 15.3
170
208 60 740 1000 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 1000 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 600 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
175
208 60 740 1000 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 1000 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 600 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
Electrical Data Without Pumps (Cont'd)
NOTES:
1. Reference PIN 59 for pump models.
2. Use this table along with Pump Electrical Data on page 46 to determine electrical data of the unit plus the pump.
3. Does not include the Control Transformer. on page 41)

York YLAA Specifications

General

Model	YLAA
Condenser	Air-Cooled
Efficiency	High Efficiency
Sound Pressure Level	Varies by model (typically 70-85 dB)
Dimensions	Varies by model
Weight	Varies by model
Category	Air-Cooled Scroll Chiller
Voltage	208-575V, 3-phase, 50/60 Hz
